HIOKI SAFETY HiTESTER 3258
Perhatian!
Spesifikasi HIOKI SAFETY HiTESTER 3258
Basic specifications (Accuracy guaranteed for 1 year, Post-adjustment accuracy guaranteed for 1 year)Regarding DMM Accuracy Due to the many ranges and functions available in a DMM, only the basic accuracy is indicated for reference. Please refer to the individual catalogs for detailed accuracy information.
| Measurement parameter | AC voltage (AC potential bridge) |
|---|---|
| Objects of measurement | Insulated conductors (IV or CV equivalent, min. 100 mm² x-section), metal conductors Note: Not usable on shielded conductors |
| Measurement range | 420.0V/ 600V AC (Auto) |
| Measurement values | True RMS |
| Max. rated voltage to earth | 600V AC rms |
| Influence of adjacent wiring | ±5% rdg. or less |
| Temperature characteristics | 0.05 % rdg./ °C |
| Display | Digital LCD, max. 4200 digit (zero suppress at 10 digits or less) |
| Display refresh rate | Approx. once every 0.6 seconds |
| Display response | 2.4 s or less |
| Functions | Data hold function, auto-power off, low battery warning |
| Power supply | LR6 (AA) alkaline battery ×6, Continuous use: 14 hr (Power ON, no measurement), or 1-minute measurements for 1000 times, or 5-minute measurements for 200 times |
| Dimensions and mass | 51mm (2.01in) W × 275mm (10.83in) H × 37.5mm (1.48in) D (one probe), 670g (23.6oz) |
| Accessories | Instruction manual ×1, LR6 (AA) alkaline battery ×6, Soft carrying case ×1 |
