CONSTANT DIGITAL MULTIMETER PD10

Update Terakhir
29-04-2016
Dilihat Sebanyak
111 kali
Lokasi
Jawa Barat - Bekasi - Bekasi Utara
Harga
Kontak Kami
Bagikan
+ Penawaran

Perhatian!

Perusahaan ini terdaftar sebagai Free Member. Hindari melakukan pembayaran sebelum bertemu penjual atau melihat barang secara langsung. COD (Cash On Delivery) atau bertemu langsung dengan penjual merupakan metode transaksi lebih aman.

Spesifikasi CONSTANT DIGITAL MULTIMETER PD10

 Features


  • Pocket size in Hard Case or Soft Case
  • Relative measurement
  • Battery life approx. 200 hours



Function Range Accuracy
AC Voltage 4/40V ±(2.3% rdg + 10 dgts)
400/500V ±(2.3% rdg + 5 dgts)
DC Voltage 400mV ±(0.7% rdg +3 dgts)
4/40/400/500V ±(1.3% rdg + 3 dgts)
Input Impedance 10MΩ (AC and DC Voltage)
Resistance 400/4k/40k/400kΩ ±(2.0% rdg +5 dgts)
4MΩ ±(5.0% rdg + 5 dgts)
40MΩ ±(10% rdg + 5 dgts)
Capacitance 4nF ±(5.0% rdg +25 dgts)
40n/400n/4µF ±(5.0% rdg + 10 dgts)
40µ/200µF ±(10% rdg + 15 dgts)
Frequency 9.999/99.99/999.9/9.999k/99.99kHz ±(2.0% rdg +5 dgts)
Duty Cycle 0.1 – 99%
Diode Read approximately forward voltage drop of the diode
Continuity If continuity exists ≤ 60Ω, built in buzzer will sound
Display 3¾ digits, 4000 counts
Battery 3V (CR 2032)
Size / Weight H108 x W56 x D11.5mm / Approx. 50g
Standard Accessories Test Leads, Hard Case / Soft Case, Battery, Manual
