CONSTANT INSULATION TESTER 2K5
Perhatian!
Spesifikasi CONSTANT INSULATION TESTER 2K5
- Analog display indicates the value of insulated resistance and digital display indicates the voltage
- Auto range with a dual scales point needle
- High voltage output indicator
- Releasing the test button automatically will discharge the capacitance of a circuit under test
- Inner battery test function is provided
- Double test switch to avoid incorrect operation
- Unique design is to protect inner circuit from wet air
- The instruments test insulation up to 100GΩ at 2500V
- Zero resistance corrector
- Low battery indication
| Test Voltage | 2500V ± 10%, DC Voltage | |||
| Range | 0 ~ 2000MΩ /1000M ~ 100GΩ (Auto Range) | |||
| 0 ~ 100MΩ | 100M ~ 50GΩ | 50G ~ 100GΩ | ||
| Accuracy Insultated | ±23°C | ±3.0% of arc | ±2.5% of arc | ±3.0% of arc |
| other | ±6.0% of arc | ±5.0% of arc | ±6.0% of arc | |
| Display | 3½ digits, 1999 counts | |||
| Battery | 8 x 1.5V (AA size), 9V Alkaline | |||
| Size / Weight | H225 x W138 x D81mm / Approx. 1200g | |||
| Standard Accessories | Test Leads, Alligator Clips, Carrying Case, Battery, Manual |
|||
