Harting Connector Han K
Perhatian!
Spesifikasi Harting Connector Han K
Features
- Combination of power and signal are in one conector
- Crimp termination for power and signal area
- Use of standard Han E and Han D contacts
Removal of power contacs
Push cross slotted screw driver in the relevant hole of the contac until it reaches the bottom
Withdraw the crimped contacts from the insert
Insert
Number of contacts 8/24 + PE
Electrical data acc to EN 61 984
Power area : 16A 230/400V 4kV 3
Rated current : 16A
Rated voltage conductor - ground : 230 V
Rated voltage conductor – conductor : 400 V
Rated impulse voltage : 4 kV
Pollution degree : 3
Pollution degree 2 also : 10A 250V 4kV 2
Signal area 10A 160V 2.5kV 3
Rated current : 10A
Rated voltage : 160V
Rated impulse voltage : 2.5 kV
Pollution degree : 3
Rated voltage acc to UL/CSA 600/ 300V
Insulation resistance : ≥ 10 Ω
Material : polyamide
Limiting temperatures : -40 C …. +125C
Flammability acc. To UL 94 : HB
Mechanical working life
Mating cycles ≥ 500
Contacts
Power contacts
Material : copper alloy
Surface
- Hard – silver plated 3µm Ag
- Hard – gold plated 2µm Au over 3µm Ni
Contact resistance : ≤ 1mΩ
- Mm2 0.5 …. 4mm2
- AWG 20 …. 12
Signal contacts
Material : copper alloy
Surface
- Hard – silver plated 3µm Ag
- Hard – gold plated 2µm Au over 3µm Ni
Contact resistance : ≤ 1mΩ
- Mm2 0.14 …. 2.5mm2
- AWG 25 …. 14
Type : Han K 8/24, Han K 4/4, Han K 4/0, Han K 4/2, Han K 6/12, Han K 6/36, Han K12/2, Han K 4/8, Han K 6/6, Han K 8/0
