Han® Thermocouple

Update Terakhir
06-11-2017
Minimum Pembelian
1 unit
Dilihat Sebanyak
129 kali
Lokasi
Jawa Barat - Bekasi
Harga
Kontak Kami
Bagikan
+ Penawaran

Perhatian!

Perusahaan ini terdaftar sebagai Free Member. Hindari melakukan pembayaran sebelum bertemu penjual atau melihat barang secara langsung. COD (Cash On Delivery) atau bertemu langsung dengan penjual merupakan metode transaksi lebih aman.

Spesifikasi Han® Thermocouple

Features:

• Suitable for Han D® / DD® inserts
• Can be combined with standard crimp contacts in one connector
   if needed
• Iron and constantan contacts according to IEC 60584 type J
• According to EUROMAP 14, Part 1
• Suitable for Han E®, Han® EE / EEE, Han® Q and Han A®
inserts
• Can be combined with standard crimp contacts in one connector
if needed
• Iron and constantan contacts according to IEC 60584 type J
• According to EUROMAP 14, Part 1
• Connector for temperature measurement conductors - Suitable
for injection moulding machines
• Iron and constantan contacts according to IEC 60584 type J
• According to EUROMAP 14, Part 1

Technical characteristics

Contacts 16
Electrical data acc. to IEC
61984
16 A 250 V 4 kV 3
Rated current 16 A
Rated voltage 250 V
Rated impulse voltage 4 kV
Pollution degree 3
Rated voltage acc. to UL 600 V
Insulation resistance ≥1010 Ohm
Limiting temperatures -40 °C ... 125 °C
Flammability (insert) acc. to
UL 94
V 0
Mating cycles ≥500
Tightening torque 0.5 Nm
Material (insert) polycarbonate
Colour (insert) RAL 7032 (light grey)
