RETSCH Drum Mill TM 300 XL
Perhatian!
Spesifikasi RETSCH Drum Mill TM 300 XL
Product Advantages
- powerful and quick grinding of large quantities
- suitable for dry and wet grinding
- variable speed, reproducible results
- suitable for long-term operations
- ball mill and rod mill modules available
- easy tilt to empty the grinding jar
- solid steel frame
- removable sample collector
- convenient parameter setting via display
- standard sizes of grinding drums from 5 to 43.4 l
- separation grid to separate sample from grinding balls (only for Ball Mill)
- funnel with handles
- guide rail allows for ergonomic removal of drum
- grinding jar with gasket for lossfree operation
- solid noise-protection hood
- emergency switch
Features
| Applications | pulverizing, mixing |
| Field of application | agriculture, biology, Chemistry, construction materials, engineering / electronics, environment / recycling, geology / metallurgy, glass / ceramics, medicine / pharmaceuticals |
| Feed material | soft, hard, brittle, fibrous - dry or wet |
| Size reduction principle | friction |
| Material feed size* | < 20 mm |
| Final fineness* | < 20 µm |
| Batch size / feed quantity* | minimum 1 l / maximum 20 l |
| Rotation speed | 0 - 80 min-1 |
| No. of grinding stations | 1 |
| Material of grinding tools | hardened steel |
| Grinding drum sizes | 5 l / 10 l / 21.7 l / 43.3 l |
| Setting of grinding time | digital |
| Drive | 3-phase asynchronous motor with frequency converter |
| Drive power | 0.75 kW |
| Electrical supply data | different voltages |
| Power connection | 1-phase |
| Protection code | IP 50 |
| Power consumption | ~ 750 W (VA) |
| W x H x D closed | 1500 x 1200 x 700 mm |
| Net weight | ~ 295 kg |
| Standards | CE |
