Backpressure Valve MODEL 6800 SERIES Kofloc
Perhatian!
Spesifikasi Backpressure Valve MODEL 6800 SERIES Kofloc
MODEL 6800 SERIES
The backpressure valve is a kind of relief valve that keeps the pressure at the front stage of a valve constant. It can
easily and quickly control the pressure of a tank with a large buffer and remove the constant flow of a mixed gas,
which cannot easily be done by general regulation valves with a subsequent stage controlling function. This new
concept of pressure regulation has been attracting much attention.
Features
-Convenient panel-mount type
- Compact design
- High-speed regulation of primary-side pressure
- This greaseless clean valve permits gas control in a pure state.
Applications
- Tank pressure control
- Constant flow control of mixed gas
Standard Specifications
|
Model |
6800A |
6800B |
6800AL |
6800BL |
|
Pressure setting |
0.01-0.3MPa |
0.01-0.6MPa |
0.01-0.3MPa |
0.01-0.6MPa |
|
Maximum exhaust flow |
1L/MIN |
0.8L/ MIN |
10L/MIN |
10L/MIN |
|
Proof pressure |
0.8MPa |
|||
|
Heat resistance |
5℃-60℃ |
|||
|
Connection end |
Rc 1/4 (standard), Rc 1/8 |
|||
|
Materials of parts in |
(A) Al, brass, NBR, POM |
|||
(Note) The maximum flow may vary depending on operating conditions.
