VULKAN FLEXIBLE COUPLINGS VULKARDAN G
Perhatian!
Spesifikasi VULKAN FLEXIBLE COUPLINGS VULKARDAN G
10.40 kNm - 81.90 kNm
Applications
Freestanding and bellhousing Genset applications
This coupling has been designed specifically for modern auxiliary and generator Applications, both for the SAE-engine drives (sizes 54-62) and for none-SAE-engine drives (size 84). The coupling is developed for freestanding applications, with the possibility to radially change the elastomer without displacing the connected units. Within the development of the new VULKARDAN GBF an axial pluggable series of the VULKARDAN G is available. This series is specially designed for bell housing applications.
Due to the element design, exceptional values for power loss can be achieved. Additionally, the system is optimized in terms of torsional vibrations by the use of a new elastomer with a corresponding torsional stiffness CTdyn. Damaging resonances are therefore eliminated from the operating speed range and effects on engine governor are prevented.
SIZE & TORQUE
K 5411....10.40
K 5415....10.40
K 5412....10.40
K 5711....16.25
K 5711.....16.25
K 5715.....16.25
K 6011.....26.00
K 6015......26.00
K 6012......26.00
K 6211......32.50
K 6215......32.50
K 6212......32.50
