Spesifikasi VULKAN COPUPLING TDS PLAFRIX
Torque range
11.5 kNm – 14.5 kNm
Applications
The TDS Plafrix combines the highly flexible VULASTIK L coupling with a Desch Planox clutch. The VULASTIK L coupling is available in different stiffness ratings so the drive system can be perfectly tuned in terms of torsional vibration. The Planox clutch is a pneumatically actuated clutch. With an operating pressure of 5.5 bar, the clutch has been adjusted to the existing air pressure, eliminating the need for an external compressor.
The torque is transmitted through organically coated dry-friction discs. Thanks to the design and high-performance coating of the surfaces, the number of friction discs can be significantly reduced in comparison with similar products.
A light weight aluminium housing protects the clutch combination and supports the output shaft with an integrated bearing.
The TDS Plafrix was designed specifically for the use in hybrid tugs for medium service operation with up to 4,000 operating hours per year.
11.5 kNm – 14.5 kNm
Applications
The TDS Plafrix combines the highly flexible VULASTIK L coupling with a Desch Planox clutch. The VULASTIK L coupling is available in different stiffness ratings so the drive system can be perfectly tuned in terms of torsional vibration. The Planox clutch is a pneumatically actuated clutch. With an operating pressure of 5.5 bar, the clutch has been adjusted to the existing air pressure, eliminating the need for an external compressor.
The torque is transmitted through organically coated dry-friction discs. Thanks to the design and high-performance coating of the surfaces, the number of friction discs can be significantly reduced in comparison with similar products.
A light weight aluminium housing protects the clutch combination and supports the output shaft with an integrated bearing.
The TDS Plafrix was designed specifically for the use in hybrid tugs for medium service operation with up to 4,000 operating hours per year.
