Spesifikasi BHS INTEGRAL GEAR UNITS VOITH

The BHS integral gear unit is the central component in turbo gear unit compressors. These compressors generate up to 250 bar of pressure and can reach volumetric flow rates of up to 600 000 m³/h. Voith's series of single-shaft and multi-shaft gear units covers a power range of 500 kW to 55 000 kW. Gear ratios from 1:1 to 1:25 are possible.


We customize our integral gear units to fit your application and meet your needs. This ensures that your system's drive design and the number of compressor stages are taken into consideration. The typical lifetime of a BHS integral gear unit is sev­eral decades and, with regular maintenance, it will outlast your system.

BHS multi-shaft integral gear units commonly achieve efficiencies of up to 98.5%, and up to 99.2% for single-shaft gear units. Our customers have trusted BHS in­tegral gear units for more than 40 years. More than 2 000 gear units of this type are operating reliably around the world, in many cases under very harsh conditions.

Beside this Voith offers also other types of turbo gear units.



Technical data



Power transmission 0.5 – 55 MW
Speeds up to 55 000 rpm
Rated output torque values up to 150 000 Nm
Efficiency up to 98.5% (99.2%)
Gear ratios 1:1 – 1:25
Compressor stages 1 – 8
Housing design cast, welded
Toothing
  • single-helical with thrust collar (standard)
  • single-helical with separate axial bearing
Design versions For drives with

  • electric motor
  • steam turbine
  • steam turbine + electric motor
  • expansion turbine
  • gas turbine
