Spesifikasi BHS PLANETARY GEAR UNITS VOITH

BHS planetary (also called ‘epicyclic’) gear units convert torque reliably and effi­ciently in turbo drive trains. Two gear unit series cover a power range from 400 kW to 45 000 kW. Gear ratios range from 1:1 to 80:1.


We customize our BHS planetary gear units to fit your application and meet your needs. This means that the driving and driven rotational direction, the toothing design, and the shape and material of the housing are all optimized to your equipment. The so-called ‘Stoeckicht principle’ ensures an ideal load balance between the sun pinion, the planet gears, and the ring gears.

These features enable a reliable and safe service life of over 250 000 operational hours. Unit efficiency can reach levels of up to 99.4 percent. This means that, as a user, you achieve a very high level of productivity and increase the effciency of your system. Planetary gear units deliver an efficiency advantage, particularly in applications where gear ratios greater than 6:1 are required.

Our customers have been placing their trust in BHS epicyclic gear units since 1932. More than 8 000 gear units of this type are in use reliably around the world, in many cases under very harsh conditions.

Beside this Voith offers also other types of turbo gear units.

Technical data



Power transmission 0.5 – 45 MW
Speeds 500 – 60 000 rpm
Rated output torque 150 – 570 000 Nm
Efficiency up to 99.4%
Gear ratio
  • compound star: 1:11 to 1:18
  • two-stage: 1:18 to 1:35
Housing design cast (standard), welded
Toothing double-helical (standard), spur
Noise emissions between 75 and 88 dB(A) at full load and rated speed
Design variants
  • integrated couplings (including on the low speed side)
  • built-in pumps
  • built-in starter drive
  • built-in rotor turning gear unit
  • with oil supply system
