voith BHS Diaphragm Couplings
Perhatian!
Spesifikasi voith BHS Diaphragm Couplings
A BHS diaphragm coupling converts torque reliably, safely, and without wear or the need for maintenance. Equipped with single or double diaphragms, these connection couplings cover a performance range between 100 and 70 000 kW.
The EconTors single diaphragm coupling runs at speeds up to 8 000 rpm in medium-speed applications, whereas the TwinTors double-diaphragm coupling is used in high-performance compressors or test rigs at speeds up to 80 000 rpm.
Designs are available for all possible connection applications. The rotor dynamics, noise, and airflow characteristics of the couplings can be optimized as needed.
BHS high-performance diaphragm couplings are extremely robust, and their ability to compensate for an angular displacement of up to 0.5 degrees increases drive train operational reliability.
Over 2 000 BHS diaphragm couplings are currently in use around the world.
Customers value these diaphragm couplings together with BHS turbo gear units.
Technical data
| Power transmission | 0.1 – 70 MW |
| Speeds | up to 80 000 rpm |
| Torque | up to 1 500 000 Nm |
| Design models | EconTors®: (single diaphragm) TwinTors®: (double-diaphragm) |
| Connection type | |
| Diaphragm-sleeve connection | |
| Meets the following standards | |
| Special designs |
