Spesifikasi EMV and EMX Heating Mantles Electromantles

EMV and EMX Electromantles : V-shaped and Spill-Proof

EMX Spill-proof Electromantles and EMV V-shaped Electromantles may accommodate 60° funnels, pear-shaped or round botom flasks. They have been designed to accept a large range of flasks and funnel sizes for added flexibility.

The stainless steel screen on all EMV models covers the heater element to protect you from shock hazards due to spills or flask breakage. The EMX models feature a stainless steel liner over the heating element to provide additional electrical and mechanical protection against spills and ensures easier cleaning.

Key Features of EMV V-shaped models

Bottom opening accommodates round bottom and pear-shaped flasks and 60° funnels of various diameters

Capacity between 10 ml to 5 litres

Coiled heating element, suspended within a thermal insulating cartridge, provides maximum heat transfer and support

"Cool-to-touch" outer casing

Maximum element temperature 450 °C

Built-in energy regulator

Replaceable insulated heater cartridge

Indicator lamps for power and heater operation

Chemically resistant polypropylene outer casing

Grounded earth screen and double fuses for added safety

Bracket for 1.3 cm support rods ( but not including support rods )

Key Features of EMX Spill-proof models

Bottom opening accommodates round bottom and pear-shaped flasks and 60° funnels of various diameters

Capacity between 500 ml to 5 litres

Coiled heating element, suspended within a thermal insulating cartridge, provides maximum heat transfer and support

"Cool-to-touch" outer casing

Maximum element temperature 450°C

Built-in energy regulator

Replaceable insulated heater cartridge

Indicator lamps for power and heater operation

Chemically resistant polypropylene outer casing

Double fuses for added safety

Grounded earth stainless steel liner to provide additional spill-proof protection

Bracket for 1.3 cm support rods ( but not including support rods )

Technical Specification

EMX/EMV Model

EMV0050

EMV0250

EMV1000, EMX1000

EMV5000, EMX5000

Flask capacity

10 - 50 ml

100 - 250 ml

500 - 1000 ml

2000 - 5000 ml

Funnel Sizes

50 - 75 mm

75 - 100 mm

100 - 200 mm

200 - 300 mm

Max element temperature

450 °C

450 °C

450 °C

450 °C

Dimensions ( D x W x H )

260 x 175 x 127 mm

260 x 175 x 127 mm

310 x 238 x 145 mm

400 x 350 x 190 mm

Shipping Weight

0.78 kg

0.78 kg

2.76 kg

5.96 kg

EMV Series Ordering Information

Model

Capacity

Electrical Requirement

EMV0050/CE

10 to 50 ml

230v 50/ 60Hz, 60 w UK and EU plug

EMV0050/CEX1

10 to 50 ml

115v 50/ 60Hz, 75 w

EMV0250/CE

100 to 250 ml

230v 50/ 60Hz, 150 w UK and EU plug

EMV0250/CEX1

100 to 250 ml

115v 50/ 60Hz, 150 w

EMV1000/CE

500 to 1000 ml

230v 50/ 60Hz, 300 w UK and EU plug

EMV1000/CEX1

500 to 1000 ml

115v 50/ 60Hz, 300 w

EMV5000/CE

2000 to 5000 ml

230v 50/ 60Hz, 800 w UK and EU plug

EMV5000/CEX1

2000 to 5000 ml

115v 50/ 60Hz, 800 w

EMX Series Ordering Information

Model

Capacity

Electrical Requirement

EMX1000/SCE

500 to 1000 ml

230v 50/ 60Hz, 240 w UK and EU plug

EMX1000/SCEX1

500 to 1000 ml

115v 50/ 60Hz, 240 w

EMX5000/SCE

2000 to 5000 ml

230v 50/ 60Hz, 600 w UK and EU plug

EMX5000/SCEX1

2000 to 5000 ml

115v 50/ 60Hz, 600 w
