Integrity 10 Reaction Station Electrothermal
Perhatian!
Spesifikasi Integrity 10 Reaction Station Electrothermal
|
Integrity 10 Reaction Station |
|
|
The Integrity 10 Reaction Station enables you to conduct 10 different reactions simultaneously within the same reaction unit, each reaction being conducted within its own cell, at its own individual temperature and stir rate. |
|
|
The Integrity 10 Reaction Station is an excellent screening tool that can be used in most laboratories. It features : |
|
|
10 individual, independently controllable cells |
|
|
Temperature range of -30 °C to 150 °C |
|
|
Stirring rate of 350 rpm - 1200 rpm |
|
|
For sample volumes of 1 ml - 25 ml |
|
|
Optional attachments for refluxing, and working under inert conditions |
|
|
Optional multi-infrared probes for solubility/crystallisation studies |
|
|
Local control via colour touchscreen |
|
|
If desired, fast heating and cooling rates can be selected, with temperature ramps of between 0.1°C/min to 5°C/min. There is also a crash function for even faster temperature changes, which is ideal for kinetic determinations. |
|
|
Extreme temperature accuracy is guaranteed, with a temperature stability of ± 0.2 °C and a maximum set point overshoot of 0.1 °C. The temperature may be maintained either through the block itself or by using a probe within each cell's solution. |
|
|
This accuracy can be maintained over a wide temperature range of -30 °C to 150 °C, with precise, independently controlled temperature profiles, and homogeneous sample mixing may be assured with stirring rates of between 350 rpm to 1200 rpm using powerful magnetic stirrers. |
|
|
The Integrity 10 is an excellent tool for establishing ideal process conditions. |
|
|
IR/NIR probe ( part no. ATS10394/1 ) custom made for Integrity 10 by Hellma. |
|
|
Visit the Amigo Chem web site for more information on how the Integrity10 can be incorporated onto a robotics platform |
|
|
Technical Specification |
|
|
Number of Positions |
10 |
|
Cell Cavity Diameter |
25.5 mm |
|
Sample Volume |
1 - 25 ml |
|
Temperature Range |
- 30 °C to + 150 °C |
|
Possible temp difference |
180 °C |
|
Temperature Overshoot |
0.1 °C ( maximum ) |
|
Max controlled heating cooling ramp rate |
0.1 °C to 5 °C min in 0.1°C min steps |
|
Stir Speed Range |
350 - 1200 rpm |
|
Viscosity Capacity |
Glycerine at 25 °C |
|
Recommended Stir Bars |
12 x 4.5 mm ( cylindrical ) or 10 x 6 mm ( oval ) |
|
Ordering Information |
|
|
Part Number |
Description |
|
PS20000 |
Integrity 10 with 10 individually controlled cells, UK , US & EU power leads |
|
ATS20100 |
Integrity 10 reflux/inerting unit |
|
ATS20002 |
SVL 22 thread inerting caps for use with ATS20100 |
|
ATS10075 |
Glass tubes 24 / 150 mm, SVL 22 thread pack of 10 |
|
ATS20003 |
Kimble thread inerting caps for use with ATS20100 |
|
ATS20004 |
Kimble thread 24 / 150 mm glass tubes compatible with ATS20003 |
|
ATS10055 |
Small volume test tubes 24 - 16 mm taper ( 3 ml ) x10 |
|
ATS10056 |
Reducing sleeves for ATS10055 x10 |
|
ATS10209 |
Small volume test tubes 24 - 11 mm taper ( 1 ml ) x 10 |
|
ATS10101 |
Reducing sleeves for ATS10209 |
|
AZS4206 |
Stirrer bars 10 / 6mm, pack of 10 |
|
AZS4235 |
Stirrer bars 12 / 4.5mm, pack of 10 |
|
ATS10001 |
Multi-Temp 10 plug-in box |
|
ATS10027 |
Temperature probe, pack of 6 |
|
ATS10027 / 10 |
Temperature probe, pack of 10 |
|
ATS11005 |
Integrity software |
|
ATS10360 / 1 |
Non Intrusive IR sensor, pack of 1 |
|
ATS10230 |
Small Intrusive IR probe in stainless steel PID-NIR5-BNSD, pack of 1 |
|
ATS10394 / 1 |
Large Intrusive IR and NIR probe pack of 1 |
