Spesifikasi Micro-Kjeldahl Extraction Heaters Electrothermal
|
MM Series Micro-Kjeldahl Extraction Heaters |
|||
|
The Micro-Kjeldahl Extraction equipment has been designed for Kjeldahl extraction on a micro scale to determine the protein content of food. |
|||
|
These multibank units have 6 recesses in a stainless steel outer casing with back-mounted brackets ( supplied with each unit ), which can hold support rods of 12.7 mm diamter max. This 6 recess model accommodates flasks of between 18 - 50 ml only. |
|||
|
Each heating mantle has its own energy regulator incorporating an On/Off switch and a "Mains to Heater" amber neon indicator. There is also a "Mains On" clear neon indicator on the front panel. |
|||
|
The lower part of the unit houses dedicated controllers for each recess. This "cool zone" housing is separated from the heating elements by a stainless steel screen and a well-ventilated air space. The heating element consists of thermally insulated element wire stitched into a cartridge, and operates up to a temperature range of 550°C to 800°C maximum. |
|||
|
The MM Micro-Kjeldahl Equipment models incorporate an earth screen to protect the user from electric shocks and are double-fused for extra safety. The rugged stainless steel outer casing is durable and easy to clean. |
|||
|
Key Features |
|||
|
Rugged, easy to clean stainless steel construction |
|||
|
Back-mounted brackets hold flask support rods ( supplied with each unit ) |
|||
|
6 positions which can accommodate flasks of between 18 - 50 ml capacity |
|||
|
Maximum element temperature range of 550 °C to 800 °C |
|||
|
Dedicated controllers for each recess are housed in a "cool zone" |
|||
|
Grounded stainless steel earth screen covering the heating element |
|||
|
Units are double fused for added safety |
|||
|
Please note that glassware is not included |
|||
|
For the fume collection tube please order AT4001 |
|||
|
Technical Specification |
|||
|
Element Tempertature Range |
550 °C to 800 °C maximum |
||
|
Case Material |
Stainless Steel |
||
|
Thermal Insulation |
Ceramic fibre mineral wool |
||
|
Clamps for Support Rods |
Fitted with adjustible brackets which accept the supplied fume tube holders |
||
|
No. of Wells |
6 |
||
|
Well Capacity |
18 – 50 ml |
||
|
Ordering Information |
|||
|
Model |
Electrical Requirements |
Dimensions ( D x W x H ) |
Weight |
|
MM2313E |
230 V, 50 60 HZ, 600W, UK plug |
160 x 520 x 162 mm |
3.5 kg |
|
MM2313EX1 |
115 V, 50 60 HZ, 600W, US plug |
160 x 520 x 162 mm |
3.5 kg |
|
MM2313EX6 |
230 V, 50 60 HZ, 600W, EU plug |
160 x 520 x 162 mm |
3.5 kg |
