Humidity Chamber HCP108, HCP153 & HCP246 Memmert

Humidity Chamber HCP108, HCP153 & HCP246 Memmert

Control of standard components

Controller

Electronic microprocessor temperature controller with auto-diagnostic system

Temperature

2 Pt100 sensors Class A in 4-wire-circuit, mutually monitoring and taking over the performance at the same temperature value

Timer

Digital 7-day programme timer with real time clock, precise minute setting

Timer

Integrated timer for tempering profiles of up to 40 ramps each, each segment adjustable from 1 min. To 999 hrs.

Controller

Digital display of all set parameters, such a temperature, weekdays, time, CO2, humidity and set-up values - language to be chosen via set-up

Humidity

Active humidifying and de-humidifying control ( 20-95 % ) with digital display of relative humidity - resolution of display 0.5 %, setting accuracy 1 %

Humidity

Humidity supply with distilled water from external tank by self-priming pump

Humidity

Active humidifying and de-humidifying adjustable from 20-95 % rh with digital display of relative humidity - resolution of display 0.5 %, setting accuracy 1 %

Humidity

Humidity supply with distilled water from external tank by self-priming pump

Humidity

Humidification by hot steam generator

Temperature

Resolution of display for setpoint values 0.1°C up to 99.9°C, 0.5°C from 100°C and for actual values

With humidity min. 8°C above ambient up to +90°C

Without humidity min. 8°C above ambient up to +160°C

Control technology

Calibration

Three freely selectable temperature values

Ventilation

Uniform atmosphere and temperature distribution owing to enclosed non-turbulent ventilation system in working chamber

Communication

documentation

Integrated ring memory as data logger for GLP-conforming long-term documentation of all relevant parameters - 1024 kB

documentation

Programme stored in case of power failure

documentation

Parallel printer interface ( incl. real time clock with date function ) for all PCL3-compatible ink jet printers for GLP-conforming documentation

Interface

USB-interface incl. Memmert software "Celsius" for programming and documentation

Programming

Chip-card control incl. 1 MEMoryCard XL with 32 kB storage capacity (max. 40 ramps)

Safety

Autodiagnostic system

Integral fault diagnostics for temperature and humidity control

Alarm

Visual and acoustic

Temperature control

Overtemperature monitor TWW, protection class 3.1 or adjustable temperature limiter TWB, protection class 2, selectable on display

Alarm

With visual and acoustic alarm in case of over-/under temperature and underhumidity, open door and empty water tank

AutoSAFETY

Additionally integrated over- and undertemperature monitor "ASF", automatically following the setpoint value at a preset tolerance range, alarm in case of over- or undertemperature, heating is switched off in case of overtemperature

Temperature control

Mechanical temperature limiter TB, protection class 1 according to DIN 12880 to switch off the heating approx. 10 °C above nominal temperature

Heating concept

Large-area multi-function heating system on four sides with additional door and back heating to avoid condensation

Standard equipment

Scope of delivery

2nd chip-card ( STERICard ) for sterilisation of working chamber with fixed values ( 4 hours/160°C ) without removal of sensors

Scope of delivery

Incl. works calibration certificate for +60°C

Door

Fully insulated stainless steel door with2-point locking (compression door lock), lockable

Door

Inner glass door

Housing

Rear zinc-plated steel

Interior

Easy-to-clean interior,made of stainless steel,reinforced by deep drawn ribbing, material 1.4301 (ASTM 304), hermetically welded

Internals

2 perforated stainless steel shelves

HUMIDY CHAMBER HCP 108

Stainless steel interior

Dimensions W x H x D

w(A) x h(B) x d(C) : 560 x 480 x 400 mm

Volume

108 Liter

Textured stainless steel casing

w(D) x h(E) x d(F) : 710 x 778 x 550 mm

Electrical data

Voltage

230 V, 50/60 Hz

Electrical load

Approx. 1000 W

Dimensions approx incl. carton

B x H x T: 830 x 1050 x 800 mm

Net weight

Approx. 70 kg

Gross weight carton

Approx. 95 kg

HUMIDY CHAMBER HCP 153

Stainless steel interior

Dimensions W x H x D

w(A) x h(B) x d(C) : 480 x 640 x 500 mm

Volume

153 Liter

Textured stainless steel casing

w(D)   x h(E) x d(F) : 630 x 938 x 650 mm

Electrical data

Voltage

230 V, 50/60 Hz

Electrical load

Approx. 1500 W

Dimensions approx incl. carton

B x H x T : 830 x 1300 x 800 mm

Net weight

Approx. 80 kg

Gross weight carton

Approx. 106 kg

HUMIDY CHAMBER HCP 246

Stainless steel interior

Dimensions W x H x D

w(A) x h(B) x d(C) : 640 x 640 x 600 mm

Volume

246 Liter

Textured stainless steel casing

w(D) x h(E) x d(F) : 790 x 938 x 750 mm

Electrical data

Voltage

230 V, 50/60 Hz

Electrical load

Approx. 2000 W

Dimensions approx incl. carton

B x H x T: 930 x 1140 x 930 mm

Net weight

Approx. 110 kg

Gross weight carton

Approx. 132 kg
