Climate Chamber ICH110, ICH260 & ICH750 Memmert
Perhatian!
Spesifikasi Climate Chamber ICH110, ICH260 & ICH750 Memmert
Climate Chamber ICH110, ICH260 & ICH750 Memmert |
|
ControlCOCKPIT |
Adaptive multifunctional digital PID-microprocessor controller with 2 high-definition TFT-colour displays |
Temperature |
2 Pt100 sensors Class A in 4-wire-circuit, mutually monitoring and taking over the performance at the same temperature value |
Humidity |
Humidity supply with distilled water from external tank by self-priming pump |
Humidity |
Humidity supply with distilled water from external tank by self-priming pump |
Humidity |
Humidification by hot steam generator |
Humidity |
Active humidifying and de-humidifying adjustable from 10-80 % rh with digital display of relative humidity - resolution of display 0.1 %, setting accuracy 0.5 % |
Timer |
Digital backwards counter with target time setting, adjustable from 1 minute to 99 days |
Temperature |
|
From -10 °C up to +60 °C without humidity |
|
From +10 °C up to +60 °C with humidity |
|
Resolution of display for setpoint and actual temp. values |
0.1 °C |
Control Technology |
|
Function SetpointWAIT |
The process time does not start until the set temperature is reached |
Language setting |
German/English/Spanish/French |
Calibration |
Three freely selectable values each, temperature/humidity/CO2 |
Adjustable parameters |
Temperature ( Celsius or Fahrenheit ), fan speed, relative humidity, programme time, time zones, summertime/wintertime |
Ventilation |
|
Fan |
Forced air circulation in working chamber adjustable from 10 to 100 % in 10 % steps |
Communication |
|
documentation |
Programme stored in case of power failure |
Programming |
AtmoConTROL software on a USB stick for programming, managing and transferring programmes via Ethernet interface or USB port |
Safety |
|
Temp. control |
Mechanical temperature limiter TB, protection class 1 according to DIN 12880 to switch off the heating approx. 10°C above nominal temperature |
Temp. control |
Over- and undertemperature monitor TWW, protection class 3.3 or adjustable temperature limiter TWB, protection class 2, selectable on display |
AutoSAFETY |
Additionally integrated over- and undertemperature protection "ASF", automatically following the setpoint value at a preset tolerance range, alarm in case of over- or undertemperature, heating is switched off in case of overtemperature, compressor in case of undertemperature |
Autodiagnostic system |
Integral fault diagnostics for temperature and humidity control |
Alarm |
Visual and acoustic |
Heating concept |
|
No drying-up of the load caused by the cooling device due to separation of thermal jacket from interior |
|
Energy-saving use of CFC-free cooling/heating system ( refrigerant R134a ) |
|
Highly efficient automatic defrosting system |
|
Air jacket heating system for gentle all-around heating |
|
Standard equipment |
|
Door |
Fully insulated stainless steel door with 2-point locking ( compression door lock ) |
Door |
Inner glass door |
Housing |
Rear zinc-plated steel |
Internals |
2 stainless steel grids |
Installation |
On lockable castors |
CLIMATE CHAMBER ICH110 |
|
Stainless steel interior |
|
Max. loading of chamber |
150 kg |
Dimensions W x H x D in mm |
W (A) x h (B) x d (C) : 560 x 480 x 400 mm |
Volume |
108 Liter |
Textured stainless steel casing |
W (D) x h (E) x d (F) : 745 x 1233 x 634 mm |
Electrical data |
|
Voltage |
230 V, 50/60 Hz |
Electrical load |
Approx. 1350 W |
Voltage |
115 V, 50/60 Hz |
Electrical load |
Approx. 1350 W |
Dimensions approx incl. carton |
B x H x T : 880 x 1410 x 810 mm |
Net weight |
Approx. 109 kg |
Gross weight carton |
Approx. 137 kg |
CLIMATE CHAMBER ICH260 |
|
Stainless steel interior |
|
Max. loading of chamber |
200 kg |
Dimensions W x H x D in mm |
W (A) x h (B) x d (C) : 640 x 800 x 500 mm |
Volume |
256 Liter |
Textured stainless steel casing |
W (D) x h (E) x d (F) : 824 x 1552 x 734 mm |
Electrical data |
|
Voltage |
230 V, 50/60 Hz |
Electrical load |
Approx. 1350 W |
Voltage |
115 V, 50/60 Hz |
Electrical load |
Approx. 1350 W |
Dimensions approx incl. carton |
B x H x T : 930 x 1760 x 930 mm |
Net weight |
Approx. 160 kg |
Gross weight carton |
Approx. 217 kg |
CLIMATE CHAMBER ICH750 |
|
Stainless steel interior |
|
Max. loading of chamber |
200 kg |
Dimensions W x H x D in mm |
W (A) x h (B) x d (C) : 1040 x 1200 x 600 mm |
Volume |
749 Liter |
Textured stainless steel casing |
W (D) x h (E) x d (F): 1224 x 1950 x 834 mm |
Electrical data |
|
Voltage |
230 V, 50/60 Hz |
Electrical load |
Approx. 1350 W |
Voltage |
115 V, 50/60 Hz |
Electrical load |
Approx. 1350 W |
Dimensions approx incl. carton |
B x H x T : 1330 x 2150 x 1050 mm |
Net weight |
Approx. 249 kg |
Gross weight carton |
Approx. 319 kg |
