Octane Analyzer K88600 Koehler Instrument
Perhatian!
Spesifikasi Octane Analyzer K88600 Koehler Instrument
|
K88600 Portable Octane Analyzer with Cetane Index and Cetane Number |
||
|
The analyzer measures octane number via near-infrared (NIR) transmission spectroscopy utilizing 14 near-infrared emitting diodes with narrow bandpass filters, a silicon detector system, and a fully integrated microprocessor. Simple octane number determination requires three easy steps: sampling a background signal, acquiring two absorption spectra of the gas sample, and then acquiring a second background signal. Analyzer is pre-calibrated for unleaded gasoline and ethanol-blended fuels, and can be calibrated for up to eight additional fuel types. |
||
|
The analyzer is small, lightweight, and operates on AA batteries or AC. Before each reading, the unit standardizes itself to assure accuracy. The octane number is printed with time and date on the built-in printer. An optional model with a GPS locator and automatic fuel selector is also available. All data can be downloaded via the RS232 port to an external computer. |
||
|
Specifications |
||
|
Accuracy and repeatability equivalent to ASTM approved CFR engines test methods ( ASTM D2699 and D2700 for Octane Number and ASTM D613 for Cetane Number ) |
||
|
Sample Holder |
Sealed, cylindrical glass container ( 75 mm optical path length ) |
|
|
Sample Volume |
8 Ounces ( approx. 225 mL ) |
|
|
Precalibrated for unleaded gasoline & ethanol-blended fuels |
Analyzer can be calibrated for up to 8 additional fuel types |
|
|
Battery operated |
6 AA batteries |
|
|
Included Accessories |
IBM Compatible Software |
|
|
RS232 Cable |
||
|
Aluminum Carrying Case |
5 Rolls of paper |
|
|
3 Sample Holders |
||
|
Light Shield |
6 AA Batteries |
|
|
6 Sample Holder Labels |
||
|
Dimensions D x W x H |
13.5 x 4.5 x 2.5 in ( 34 x11.5 x 6.25 cm ) |
|
|
Net Weight |
12 lbs ( 5.5 kg ) |
|
|
Shipping Information |
23 x 17 x 8.5 in ( 58.5 x 43.25 x 22 cm ) |
|
|
Shipping weight |
25 lbs ( 11.5 kg ) |
|
|
Ordering Information |
||
|
P/N |
Description |
Electrical |
|
K88600 * |
Portable Octane Analyzer |
115V/240V 50/60Hz |
|
K88600-GPS |
Portable Octane Analyzer GPS Model Requires GPS Locator Feature |
115V/240V 50/60Hz |
|
Accessories |
||
|
P/N |
Product Description |
|
|
K88601 |
Printer Paper, 10 Rolls |
|
|
K88602 |
Additional Fuel Calibration |
|
|
K88603 |
Sample Holder ( additional ) |
|
|
K88604 |
Sample Holder ( Box of 12 ) |
|
|
K88605 |
Light Shield |
|
|
K88606 |
RS232 Cable |
|
|
K88607 |
Aluminum Sample Carrying Case w/12 Sample Holders |
|
|
K88608 |
Sample Holder Lids, 12 |
|
|
K88609 |
Sample Holder Labels, 12 |
|
|
K88610 |
25 Sample Memory |
|
|
K88612 |
Cetane Index and Cetane Number |
|
|
K88613 |
GPS Locator ( for K88600-GPS model only ) |
|
