Flexible Conduit Stainless Steel 3/4 Inch HRLM NGd Ex-Proof Flexible Conduit

Jual Flexible Conduit Stainless Steel 3/4 Inch HRLM NGd Series Ex-Proof Flexible Conduit Jakarta Indonesia

HRLM NGd Series EXPLOSION PROOF FLEXIBLE ConDUIT ( dII, DIP )


APPLICATION

* Designed for Explosive Atmosphere Zone 1, Zone 2 and Combustible dust Zone 20, Zone 21, Zone 22.
* Designed for Groups IIA, IIB, IIC.
* Designed for Petroleum Exploitation, Refinery, Chemistry Medicine, Textile, Painting, Military and Military Facilities etc, Sites with Explosive Atmosphere.

FEATURES

* Explosion Proof Flexible Conduit is consist of Ex union and connection pipe, connection pipe is consist of innerpipe and sheath.
* Ex union is made of stainless steel or galvanized carbon steeel.
* Inner pipe is made of corrugated pipe or metal flexible conduit with good corrosion resistance.
* With features of flame resistance, corrosion resistance, aging resistace. good flexibility, reliable work etc.
* Thread size and specification can be made as per request, such as NPT, Metric etc.
* Normal provided length is 500mm. 700mm, 1000mm, other length need please indicate when ordering.
* Thre different materials for selection.

 TECHNICAL SPECIFICATION

* Compliance with : GB 3836. 1, GB 3836. 2, GB 12476. 1, JB/T 9600, IEC60079-0, IEC-60079-1, IEC61241-1-1

* Explosion Protection : Exd II DIP A20

* Ingress Protection : IP65


----------------------------------------------------------------------
