Spesifikasi HIOKI RESISTANCE METER RM3548
HIOKI RESISTANCE METER RM3548
3-Range, 250 to 1000V Analog Insulation Resistance Tester with Continuity Check
Hioki insulation resistance testers or megohmmeters feature all-in-one designs including built-in rugged cases and test lead storage compartments. The 3490 is a 3-range, 250/500/1000V analog insulation resistance meter with efficient functions and features to help shorten work time associated with field insulation testing.
Overview
- 0.02 % basic accuracy, 0.1 μΩ max. resolution, 1 A max. testing current, 1A max. testing current
- Measure from 0.0 µΩ (testing current 1 A) to 3.5 MΩ
- Easily record up to 1,000 data points in memory simply by applying the instrument’s probes
- Smoothly capture temperature-rise test data using interval measurement
- Portable design is ideal for maintenance and testing of large equipment
Specification
|
Resistance range |
3 mΩ (3.5000 mΩ display Max., 0.1 µΩ resolution) to 3 MΩ range (3.5000 MΩ display Max., 100 Ω resolution), 10 steps Measurement accuracy: ±0.020 % rdg. ±0.007 % f.s. |
|
Testing current |
[at 3 mΩ range] 1 A DC to [at 3 MΩ range] 500 nA DC |
|
Open-terminal voltage |
5.5 V DC max. |
|
Temperature measurement |
-10.0 to 99.9°C, accuracy: ±0.50°C (Temperature Sensor Z2002 and RM3548 combined accuracy) |
|
Measurement speed |
Fixed |
|
Display refresh rate |
Without OVC: approx. 100ms, With OVC: approx. 230ms |
|
Functions |
Temperature correction, temperature conversion, offset voltage compensation (OVC), comparator (ABS/REF%), length conversion, judgment sound setting, auto hold, auto power save (APS), Averaging, panel store/panel load, USB communication interface (RM3548 internal memory is recognized as a mass storage device when connected to a PC) |
|
Memory storage |
Number of recordable data points: (manual/auto) Up to 1,000, (interval) Up to 6,000; Interval: 0.2 to 10.0s (0.2s steps); Acquisition of data from memory: display, USB mass storage (CSV, TXT files) |
|
Power supply |
LR6 (AA) Alkaline batteries ×8, Continuous use: 10 hours (Under our company’s conditions), Rated power consumption: 5 VA |
|
Dimensions and mass |
192 mm (7.56 in) W × 121 mm (4.76 in) H × 55 mm (2.17 in) D mm, 770 g (27.2 oz) |
|
Accessories |
Clip type lead 9287-10 ×1, Temperature sensor Z2002 ×1, LR6 Alkaline battery ×8, Instruction manual ×1, USB Cable(A-to-mini B type) ×1, Strap ×1, Spare fuse ×1 |
