Spesifikasi Laser Technology TruPulse 360° Laser Rangefinder / Hypsometer

Detail Produk Laser Technology TruPulse 360° Laser Rangefinder / Hypsometer

Description :

The Laser Technology TruPulse® 360 Range Finder is a great optical and infrared laser surveying tool that features exclusive TruVector Compass Technology which allows you to reach your target from any angle, making every measurement safe and accurate. No matter how difficult the conditions are, or what angle you shoot from, the TruPulse® 360 will give you the best measurement possible. The TruPulse® 360 laser range finder takes measurements up to 3,280 ft and a maximum of 6,560 ft to reflective targets with an accuracy of 1 ft.

The TruPulse® 360 range finder integrates with GPS and GIS software to easily enhance your geographical data positioning a target remotely when you integrate your GPS or even adding height values in your GIS.

The 3-shot height routine is phenomenal for vertical targets, like phone poles or buildings, even when taking your measurements under rough conditions. On projects where you encounter leaning objects or even wires or a bridge, the vertical distance and missing line modes are great features to get perfect measurements.

The TruPulse® 360 professional rangefinder uses TruVector and TruTargeting technology to automatically provide you with the best accurate distance to a given target. Its integrated compass allows you to measure azimuth, which it is basically the distance measured in an angle, and it even gives you the option to measure distance, inclination and azimuth between two remote points.

The powerful TruPulse® 360 Range Finder gives you a variety of solutions for your measurements. It measures horizontal, vertical and slope distance, degrees and percent slope inclination, height using its 3-shoot height routine, azimuth from 0 to 359.9 degrees and distance, inclination and azimuth between two remote points. You can also take your measurements in different units: feet, meters, yards, degrees and percent.

Easily spot your targets with the 7X magnification and you never lose sight of your measurements since this range finder tool is equipped with in-scope data display, which allows you to navigate through menus and displays all your data right in the scope. It also comes with an adjustable eyepiece that makes possible to use eyeglasses or sunglasses while taking your measurements. Once you gather all your data, it can be transferred with the RS232 serial port. The overall experience with the TruPulse® 360 Range Finder is unbeatable, easy to carry and manage, it only weights 8 ounces and it comes with its carrying case.

You can attach your laser rangefinder to a ¼-20 female thread tripod and 2 AA batteries give you a minimum of 8 hours of continuous use or  you can also use a CRV3 battery.

Features:

  • TruVector Compass Technology – Gives you the ability to shoot from any angle
  • Measurement range up to 3280 ft (1000 m)
  • Inclination
  • High accuracy
  • Small size
  • Light weight
  • Data Communication (Serial, via wired RS232)
  • Water and Dust Resistant
  • Wide temperature range
  • 7X Magnification
  • Feet, Yards, Meters, Degrees, & Percent Slope Units
  • Monopod / Tripod mountable

Specifications:

  • Measurement Range: Distance: 3,280 ft; typical, 6,560 ft; max to reflective target; Inclination: ±90 Degrees; Azimuth: 0 to 359.9 degrees;
  • Accuracy:  Distance: ±1 ft; typical, ±1 yd; to low quality targets; Inclination: ±0.25 Degrees; Azimuth: ±1 degree, typical.
  • Units:   Feet, Yards, Meters, Degrees, and Percent Slope
  • Dimension (in):   5 x 2 x 3.5
  • Weight (oz): 8

What’s in the Box:

  • (1) TruPulse 360° Laser Rangefinder/Hypsometer
  • (1) Neck strap
  • (1) Belt pouch
  • (1) Lens cloth
  • (1) User manual
