General
– Water proof/Submersible IPX7
– Frekwensi range : VHF 136 – 174 Mhz
– Modulation : F3E(FM)
– Channel Step : 5,10, 20,25 & 30 Khz
– Antena impedance : 50 Ohm
– Frequency Stability : + 2.5 ppm
– Power Supply : DC 7.0 – 16.0 V ( External DC-IN)
– Large capacity battery 1600mA Lithium-ions
– Dimension : 58(w)x110(H)x34(D)mm
– Weight : 270 g
Transmitter
– Output power : 5 watt
– Modulation : Variable reactance frequency modulation
– Supriuos emission : -60dB or less
– Max. deviation : WFM +5KHz/NFM +2.5KHz
– Mic. Impedance : 2Kohm
Receiver
– Receive system : Double conversion superheterodyne
– Intermediate frequency : 1st IF : 38.85MHZ/2nd IF : 450KHz
– Sensitivity : VHF -14.0dBu(0.25 uV) or less
(12dB SINAND) UHF -12.0dBu(0.25uV) or less
– Selectivity : – 6 db: 12KHz or more/-60dB: 35 KHz
– Audio Output power : 500mWatt
