Sieve Shaker AS 200 Control Retsch
Perhatian!
Spesifikasi Sieve Shaker AS 200 Control Retsch
|
Vibratory Sieve Shaker AS 200 Control Retsch |
|
|
The analytical sieve shakers of the series AS 200 are used in research & development, quality control of raw materials, interim and finished products as well as in production monitoring. |
|
|
The controllable electromagnetic drive offers an optimal adaption for every product. Sharp fractions are obtained even after very short sieving times. |
|
|
With its all-digital controls, up to 99 sieving programs and calibration certificate the sieve shaker AS 200 control is indispensable for all users who attachimportance to precision and operational convenience and need to comply with the guidelines of the ISO 9001. |
|
|
Application Examples |
|
|
Cement clinker, chemicals, coffee, construction materials, fertilizers, fillers, flours, grains, metals powders, minerals, nuts, plastics, sand, seeds, soils, washing powder, ... continue to application database |
|
|
Product Advantages |
|
|
NEW : up to 99 sieving programs |
|
|
NEW : low noise operation thanks to optimized control |
|
|
NEW : USB connection for use of EasySieve software |
|
|
Suitable for dry and wet sieving |
|
|
Excellent separation efficiency even with short sieving times |
|
|
Efficient electromagnetic drive |
|
|
3-D throwing motion which ensures optimum use of the open sieve area and lets the sample move equally over the whole sieving surface |
|
|
Setting of sieve acceleration "g" for comparable and reproducible sieving results worldwide |
|
|
Sieve stack up to 620 mm height |
|
|
Free digital adjustment of all process parameters ( time, amplitude or sieve acceleration, interval ) |
|
|
Interval operation |
|
|
Optional sieve software EasySieve for control of the shaker, easy evaluation & documentation of results |
|
|
Fulfils all criteria for measuring equipment related to ISO 9001 |
|
|
Calibration certificate |
|
|
Easy operation, ergonomic design |
|
|
Maintenance-free |
|
|
Features |
|
|
Applications |
Separation, fractioning, particle size determination |
|
Field of application |
Agriculture, biology, chemistry / plastics, construction materials,engineering / electronics, environment / recycling, food, geology /metallurgy, glass / ceramics, medicine / pharmaceuticals |
|
Feed material |
Powders, bulk materials, suspensions |
|
Measuring range* |
20 µm - 25 mm |
|
Sieving motion |
Throwing motion with angular momentum |
|
Max. batch / feed capacity |
3 kg |
|
Max. number of fractions |
11 - 23 |
|
Max. mass of sieve stack |
6 kg |
|
Amplitude |
Digital, 0.2 - 3 mm |
|
Controlled amplitude |
Yes |
|
Sieve acceleration |
1.0 - 15.1 g |
|
Time display |
Digital, 1 - 99 min |
|
Interval operation |
1 - 99 s |
|
Storable SOPs |
99 |
|
Suitable for dry sieving |
Yes |
|
Suitable for wet sieving |
Yes |
|
USB interface |
Yes |
|
Including test certificate/can be calibrated |
Yes |
|
Suitable sieve diameters |
100 mm / 150 mm / 200 mm / 203 mm ( 8" ) |
|
Max. height of sieve stack |
620 mm |
|
Clamping devices |
"Standard", "comfort", each for wet and dry sieving |
|
Protection code |
IP 54 / IP 20 |
|
Electrical supply data |
100-240 V, 50/60 Hz |
|
Power connection |
1 phase |
|
W x H x D |
417 x 212 x 384 mm |
|
Net weight |
~ 35 kg |
|
Standards |
CE |
