Spesifikasi Bellows Seal Globe Valves

 1. DIN Bellows Sealed Globe Valves1. DIN Bellows Sealed Globe Valve Material:

* GS-C25/GS-C25N/GP240GH/1.0619


2. DIN Bellows Sealed Globe Valve Pressure rating and size:
* PN10~PN40 : DN15~DN400


3. DIN Bellows Sealed Globe Valve Features:
* Designs: DIN 3356/ BS 1414

* Face to face: BS 2080/ DIN 3202

* Flange ends: ISO7005-1/ DIN3543-2545

* Test: DIN 3230

* Body type: Straight, Y Type, angle type


4. DIN Bellows Sealed Globe Valve Applications:
* Chemical, Petrochemical, Oil & Gas, Power Plant, General Industry etc.

5. DIN Bellows Sealed Globe Valve Structure:
* BB : bolt bonnet
* OS & Y : outside screw and yoke

6. DIN Bellows Sealed Globe Valve Temperature rating:
* -45°C - + 650 °C or above

7. DIN Bellows Sealed Globe Valve Operators:
* Pneumatic / Electric/ Gear box/ Locking Device/ Handwheel etc.

 Material:

* GS-C25/GS-C25N/GP240GH/1.0619



2. DIN Bellows Sealed Globe Valve Pressure rating and size:

* PN10~PN40 : DN15~DN400



3. DIN Bellows Sealed Globe Valve Features:

* Designs: DIN 3356/ BS 1414

* Face to face: BS 2080/ DIN 3202

* Flange ends: ISO7005-1/ DIN3543-2545

* Test: DIN 3230

* Body type: Straight, Y Type, angle type



4. DIN Bellows Sealed Globe Valve Applications:

* Chemical, Petrochemical, Oil & Gas, Power Plant, General Industry etc.



5. DIN Bellows Sealed Globe Valve Structure:

* BB : bolt bonnet

* OS & Y : outside screw and yoke



6. DIN Bellows Sealed Globe Valve Temperature rating:

* -45°C - + 650 °C or above



7. DIN Bellows Sealed Globe Valve Operators:

* Pneumatic / Electric/ Gear box/ Locking Device/ Handwheel etc.



Manufacturer: Jonloo Valve Manufacturer Company

Sales Contact: Jeasin Lee

Sales email: info@jonloovalves.com

Tampilkan Lebih Banyak

Jonloo Valve Manufacturer Company

Jonloo Valve Manufacturer Company produces kinds of industrial valves, including ball valve, gate valve, check valve, globe valve, butterfly valve, plug valve, strainer and etc, in sizes varying from 1/2" to 80", with pressure ranging from 150LB to 2500LB. All of Jonloo valves are manufactured according to strict specifications and industry standards, such as ANSI, API, BS, DIN, JIS. We also provide pipes and pipe fittings. Pipes include steel pipe, galvanized pipe and plastic pipe. Pipe fittings cover bend, elbow, reducer, flange, tee, coupling, o-let and others. Jonloo Valves is continuously developing innovative technology and trying to maximize customer satisfaction.
