Ovens DKG Series Yamato Scientific

Industrial Constant Temperature Ovens Rapid heat & cool, Forced Convection Yamato Scientific

Model DKG 610, DKG 610V, DKG 650, DKG 650V, DKG 810, DKG 810V, DKG 850, DKG 850V

Specifications

Product code

212884

212885

212886

212887

Model

DKG610

DKG610V

DKG650V

DKG650

System

Forced convection

Performance

Operating temp. range

Room temp. + 30 to 260 ⁰C

Temp. adjustment accuracy

±0.5 ⁰C

Temp. distribution accuracy

±2 ( at 200 ⁰C), ±2.5 ( at 260 ⁰C )

Time to attain max. temp.

Within 45 min. from 25 ⁰C-->260 ⁰C

Temp. decrease time

about 30 min. from 260 ⁰C-->50 ⁰C

Configuration

Air supply/exhaust damper

Front operation/manual damper Air supply pipe/exhaust pipe at the rear NSSC180 With exhaust duct

Interior/exterior

Stainless steel plate/chrome free electro galvanized steel plate Chemical proof baking finish

Heater and heat insulator

SUS pipe heater & glass wool

Heater capacity

200 to 220 V 2.6 to 3.15 kW 230 to 240 V

2.6 to 2.83 kW 200 to 240 V

Blower fan

Sirocco fan x 1

Fan motor

Capacitor 30 W x 1

Cable port

I.D.: 30 mm One at the right side of the main body

Door packing

Silicon rubber

Fluororubber

Silicon rubber

Fluororubber

Air supply port

Bottom of heater room ( open/close with a manual damper )

Exhaust port

Upper part of rear of the main body: 80φ ( open/close with a manual damper )

Damper control

linked air supply/exhaust with manual knob on the front of the main body

Heater control

SSR control

Sensor

K-thermocouple ( both for inside the chamber and heater room )

Safety unit

Self diagnostic function ( temperature sensor error, heater disconnection, SSR short-circuit, automatic overheat prevention function ), key lock, program lock, overheat preventive device, over current electric leakage breaker, door switch, temperature fuse, external alarm terminal

Standards

Internal chamber size

W 600 x D 500 x H 500 mm

External size

W 770 x D 696 ( 846 ) x H 985 mm Size in the parenthesis includes the exhaust duct.

Internal volume

150 L

Withstand load of shelf

15 kg/unit

No.of internal shelf stages

7 stages

Shelf support pitch

60 mm pitch

PS ( 50/60 ) Hz rated current

200 to 220 V 13 to 15 A（ 20 A )

230 to 240 V 12 to 12.5 A（ 15A ）

Weight

100 kg

Accessories

Shelf

Stainless steel punched metal ( The bottom one shelf is fixed with screws )

2

Shelf support

4

Product code

212888

212889

212890

212891

Model

DKG810

DKG810V

DKG850

DKG850V

System

Forced convection

Performance

Operating temp. range

Room temperature + 30 to 260 ⁰C

Temp. adjustment accuracy

±0.5 ⁰C

Temp. distribution accuracy

±2 ( at 200 ⁰C ), ±2.5 ( at 260 ⁰C )

Time to attain max. temp.

Within 50 min. from 25 ⁰C-->260 ⁰C

Temp. decrease time

about 40 min. from 260 ⁰C-->50 ⁰C

Configuration

Air supply/exhaust damper

Front operation/manual damper Air supply pipe/exhaust pipe at the rear NSSC180 With exhaust duct

Interior/exterior

Stainless steel plate/chrome free electro galvanized steel plate Chemical proof baking finish

Heater and heat insulator

SUS pipe heater & glass wool

Heater capacity

220 V 3.6 to 4.36 kW

230 to 240 V 3.6 to 3.92 kW

Blower fan

Sirocco fans x 2

Fan motor

Capacitor 30 W x 2

Cable port

I.D.: 30 mm One at the right side of the main body

Door packing

Silicon rubber

Fluororubber

Silicon rubber

Fluororubber

Air supply port

Bottom of heater room ( open/close with a manual damper )

Exhaust port

Upper part of rear of the main body : 80φ ( open/close with a manual damper )

Damper control

linked air supply/exhaust with manual knob on the front of the main body

Heater control

SSR control

Sensor

K-thermocouple ( both for inside the chamber and heater room )
