Automatic Water Still WS-400 Suntex Instrument
Perhatian!
Spesifikasi Automatic Water Still WS-400 Suntex Instrument
|
Automatic Water Still WS-400 Suntex Instrument |
|
|
Specifications |
|
|
Controling method |
Microprocessor controlled |
|
Production per hour |
4 Liters / hours |
|
Temp. of condenser inlent water |
Suggusted temperature : lower than 35 °C |
|
Pressure of condenser inlent water |
70-560 kPa |
|
Flow of condenser inlent water |
1 Liter/min |
|
pH value |
5.0 ~ 6.5 |
|
Conductivity |
1.00 ~2.00 µS/cm |
|
Water Quality monitoring |
Display the conductivity of distilled water |
|
Boiler and condenser |
1 set |
|
Heating equipments |
2 quartz heating pipes |
|
Safety Protection |
YES |
|
Boiler liquid level control |
YES |
|
Water container liquid level |
YES |
|
Ambient temperature |
0 ~ 50 °C |
|
Storage temperature |
0 ~70 °C |
|
Power supply |
AC 220V ±10%, 50,60Hz |
|
Applied power |
3.2 kW |
|
Connection |
Tap water: 3/8" ID, |
|
Pretreated: 1/4" NPT ( M ), Drain: 3/8 ID |
|
|
Installation |
Benchtop or wall mounting |
|
Dimension ( W x H x D ) |
570 x 380 x 250 mm |
|
Weight |
17.6 kg |
WS Series
Automatic Water Still
4L/hr, 8L/hr, and 4L/hr Double distilled
|
Automatic operation with built-in conductivity monitor |
|
The SUNTEX Microprocessor automatic water still is available with output of 4L/hr or 8L/hr, and can be benched or wall mounted. The water still produces the very highest quality pyrogen free water. Purity is also assured through the borosilicate glass ( Boilers and Condensers ) construction and the use of durable, silica sheathed heating elements. |
|
Convenient automatic operation : |
|
Combined with the microprocessor, the unique WS series water still simplifies operation and cleaning procedures. The still is supplied with a float switch which automatically shuts off the water still when the storage reservoir is full, enabling safe, unattended operation. |
|
Safety in operation : |
|
A high temperature cut-off system protects the heaters in the events of water-input failure and low level of water in boiler. The heater can be recovered from the automatic overheating cut-off by reset. |
|
Pretreated feed option : |
|
All stills can be used with pretreated reverse osmosis ( RO ), deionized or purified water. The pretreatment removes many contaminants from feed water to keep the glass clean. |
|
Features : |
|
Highest purity, pyrogen free distillate |
|
Advanced microprocessor control & front panel keypad design for easy operation |
|
Output of 4L/hour, 8L/hour, & 4L/hour Bi-distilled |
|
Multi-color LED indication alarm for easy status recognition |
|
Built-in conductivity measurement system to ensure quality of outlet water |
|
Auto condenser clean function with detergent adding flow cell for easy maintenance |
|
Built-in liquid level switches for auto shutting off when the storage reservoir is full |
|
Overheating cut-off protection for safe operation |
|
Auto diagnosis when powering on the system |
|
Installation of benchtop or wall mounting |
