Turbidity Meter TN100 Eutech Instruments
Perhatian!
Spesifikasi Turbidity Meter TN100 Eutech Instruments
|
Turbidity Meter TN100 Eutech Instruments |
|
|
Product Features |
|
|
IP67 Waterproof and Dustproof - Cleaning and maintenance is simple. It floats! |
|
|
Automatic Push-Button Calibration ( 4 points ) for unprecedented full-range accuracy |
|
|
Sturdy Carrying Kit complete with 4 calibration standards, 3 empty cuvettes, batteries and comprehensive instruction manual |
|
|
Power-saving feature allows over 1200 measurements to be taken with a single set of AAA alkaline batteries |
|
|
Large Easy-to-Read Display for optimum viewing of measurements with user-friendly message codes for easy troubleshooting |
|
|
Meets Performance Criteria as specified by ISO 7027 ( DIN EN 27027 ) method |
|
|
The microprocessor-based waterproof TN100 meter is an easy-to-use turbidimeter that meets the rigor of rugged field applications. It is a "must -have" for anyone monitoring turbidity on the go. Using an Infrared light source, it delivers laboratory accuracy with a resolution of 0.01 NTU across an extended range of up to 20 NTU ( Nephelometric Turbidity Units ). |
|
|
Specification |
|
|
Product |
Description |
|
Measuring Parameter |
Turbidity |
|
Highlights |
Light weight, IP67 waterproof meter |
|
Principle |
Nephelometric non-ratio / ISO 7027 and DIN 27027 compliant |
|
Range |
0 to 2000 NTU |
|
Automatic Range Selection |
0.01 to 19.99 NTU; |
|
20.0 to 99.9 NTU; |
|
|
100 to 2000 NTU |
|
|
Resolution |
0.01 NTU ( 0 to 19.99 NTU ); |
|
0.1 NTU ( 20.0 to 99.9 NTU ); |
|
|
1 NTU ( 100 to 2000 NTU ) |
|
|
Accuracy |
< 0.1 NTU for 0.02 NTU standard; |
|
±2 % of reading ±1 digit for 0 to 500 NTU; |
|
|
±3 % of reading ±1 digit for 501 to 2000 NTU |
|
|
Repeatability |
< or = ±1 % of reading |
|
Calibration |
Up to 4 points |
|
Calibration Standards |
0.02 NTU, 20.0 NTU, 100 NTU, 800 NTU |
|
Response Time |
< 6 secs for full step change |
|
Sample Volume |
10 mL |
|
Light Source |
Infrared-emitting diode ( 850 nm wavelength ) |
|
Operating Temp.Range |
0 to 50 ºC |
|
Sample Temp. Range |
0 to 50 ºC |
|
Enclosure Type & Rating |
ABS plastic & IP67 rated |
|
Power |
4 x 1.5 V ‘AAA’ alkaline batteries ( > 1200 readings ) |
|
Certifications/Compliance |
FCC part 15 class A, TUV 3 in 1, CE, RoHS |
|
Dimensions ( L x W x H ) |
Meter : 15.5 x 6.8 x 4.6 cm |
|
Boxed : 35.5 x 16.5 x 10.5 cm |
|
|
Weight |
Meter : 200 g |
|
Boxed : 1,160 g |
|
|
Order Information |
|
|
Order No. |
Item |
|
ECTN100IR |
Waterproof TN-100 handheld turbidimeter with set of 4 calibration standards ( 800, 100, 20.0 & 0.02 NTU ), set of 7 sample vials, lint-free cloth, silicone oil, batteries, and hard carrying case |
|
ECTN100NOSTDS |
Waterproof TN-100 handheld turbidimeter, set of 7 sample vials, lint-free cloth, silicone oil, batteries, and hard carrying case |
|
TN100CALKIT |
Calibration kit set – standard solutions ( 0.02, 20.0, 100, 800 NTU ) 60 mL each and ( 4 ) vials |
|
ECTN100CUVKIT |
Pack of 3 cuvettes ( vials ) |
|
ECTN100CUVKIT4 |
Pack of 4 cuvettes ( vials ) |
|
ECSILICONEOIL |
Silicone oil ( 10 mL ) |
|
32X366401 |
Replacement light shield cover |
|
67X357201 |
Replacement cloth |
