Disintegration Tester 301 Ethik Technology
Perhatian!
Spesifikasi Disintegration Tester 301 Ethik Technology
Disintegration Tester 301 Ethik Technology |
|||||
Product description |
|||||
Disintegration testing determines whether tablets or capsules disintegrate within a defined period of time when placed in a liquid medium compliant with USP |
|||||
Exterior : corrosion resistant treatment and epoxy powder coated |
|||||
Stainless Steel ( AISI 304 ) basket rack |
|||||
Technical Characteristics |
|||||
Temperature control and reading through sensor PT100 with 0,1 ⁰C resolution |
|||||
Run-time and temperature microprocessed control, digital LCD display, sound alarm for end of test warning. |
|||||
Immersion heater and circulator module guarantees temperature stability of the water bath and no vibration |
|||||
Simple operation and easy cleaning baskets and bath |
|||||
Lift-out of the baskets is performed manually or automatically ( depending on model ) |
|||||
Acrylic water bath with frontal drain. |
|||||
Available Disintegration Tester models |
|||||
301/AC |
Lift-out of the baskets is performed manually; 01, 03 or 06 simultaneously driven baskets |
||||
301/AUT |
Lift-out of the baskets is performed automatically; 01, 03 or 06 simultaneously driven baskets |
||||
301/IND |
Lift-out of the baskets is performed independently; 03 or 06 baskets |
||||
301/AUT IND |
Lift-out of the baskets is performed automati- cally and independently; 03 or 06 baskets |
||||
Technical Specifications |
|||||
Temp. range |
Amb +5 °C to 50 ºC |
||||
Temp. control resolution |
±0,1 |
||||
Temp. uniformity at 37 ºC |
±0,5 |
||||
Digital Timer |
Programmable up to 99 h |
||||
RPM |
29 and 32 RPM. |
||||
Output |
4 to 20 ma |
||||
Heating system |
Stainless steel tubular resistance |
||||
Eletrical specs |
110 V or 220 V 50 Hz/60 Hz |
||||
Protection grade |
IP 20 |
||||
Included Accessories & Components |
|||||
Operational manual |
|||||
RBC Calibration Certificate, for temperature controller |
|||||
Connection for Data Logger ( 4 to 20 mA )/td> |
|||||
Optional |
|||||
IQ and OQ qualification protocols |
|||||
This Equipment Attends American Pharmacopeia Specifications USP |
|||||
Included Acessories |
|||||
Racks |
Glass Vessels |
Baskets |
Tester Tubers |
Acrylic Disc |
|
1 |
1 |
1 |
6 |
6 |
|
3 |
3 |
3 |
18 |
18 |
|
6 |
6 |
6 |
36 |
36 |
|
Information by Model 301 series |
|||||
Racks |
Width mm |
Depth mm |
Height mm |
Electrical Specs W |
Weight Kg |
1 |
400 |
280 |
600 |
700 |
32 |
3 |
680 |
280 |
600 |
700 |
39 |
6 |
1200 |
280 |
600 |
1300 |
52 |
