Jual Pompa Grundfos Sentrifugal Multi stage
Gambar Produk
Jual Pompa Grundfos Sentrifugal Multi stage
Update Terakhir
29-06-2018
Minimum Pembelian
1 unit
Dilihat Sebanyak
29 kali
Lokasi
Jawa Timur - Surabaya
Harga
Rp. 100
Bagikan
+ Penawaran
Perhatian!
Perusahaan ini terdaftar sebagai Free Member. Hindari melakukan pembayaran sebelum bertemu penjual atau melihat barang secara langsung. COD (Cash On Delivery) atau bertemu langsung dengan penjual merupakan metode transaksi lebih aman.
Spesifikasi Jual Pompa Grundfos Sentrifugal Multi stage
Jual Pompa Grundfos Sentrifugal Multi stage Stainless Steel Type CR, merupakan pompa tekanan tinggi, hubungi : Mitra Water 0822 3333 4224
Spesifikasi Pompa Grundfos Sentrifugal Multi stage :
| SMALL CR | ||||
| Pump | Product | Flow/Head at Max. | P2 | |
| Model | Number | Efficiency | (kW) | |
| CR1 | ||||
| CR 1-02 | 96516169 | 1.8 m3/h @ 11 m | 0,37 | |
| CR 1-03 | 96516170 | 1.8 m3/h @ 15 m | 0,37 | |
| CR 1-04 | 96516172 | 1.8 m3/h @ 19 m | 0,37 | |
| CR 1-05 | 96516173 | 1.8 m3/h @ 23 m | 0,37 | |
| CR 1-06 | 96516174 | 1.8 m3/h @ 27 m | 0,37 | |
| CR 1-07 | 96516176 | 1.8 m3/h @ 31 m | 0,37 | |
| CR 1-08 | 96516177 | 1.8 m3/h @ 36 m | 0,55 | |
| CR 1-09 | 96516178 | 1.8 m3/h @ 40 m | 0,55 | |
| CR 1-10 | 96516180 | 1.8 m3/h @ 44 m | 0,55 | |
| CR 1-11 | 96516181 | 1.8 m3/h @ 47 m | 0,55 | |
| CR 1-12 | 96516183 | 1.8 m3/h @ 53 m | 0,75 | |
| CR 1-13 | 96516185 | 1.8 m3/h @ 57 m | 0,75 | |
| CR 1-15 | 96516186 | 1.8 m3/h @ 64 m | 0,75 | |
| CR 1-17 | 96516188 | 1.8 m3/h @ 74 m | 1,1 | |
| CR 1-19 | 96516190 | 1.8 m3/h @ 84 m | 1,1 | |
| CR 1-21 | 96516192 | 1.8 m3/h @ 90 m | 1,1 | |
| CR 1-23 | 96516193 | 1.8 m3/h @ 97 m | 1,1 | |
| CR 1-25 | 96516255 | 1.8 m3/h @ 111 m | 1,5 | |
| CR 1-27 | 96516256 | 1.8 m3/h @ 120 m | 1,5 | |
| CR 1-30 | 96516257 | 1.8 m3/h @ 132 m | 1,5 | |
| CR 1-33 | 96516258 | 1.8 m3/h @ 149 m | 2,2 | |
| CR 1-36 | 96516259 | 1.8 m3/h @ 162 m | 2,2 | |
| CR 3-02 | 96516590 | 3 m3/h @ 9 m | 0,37 | |
| CR 3-03 | 96516591 | 3 m3/h @ 15 m | 0,37 | |
| CR 3-04 | 96516592 | 3 m3/h @ 19 m | 0,37 | |
| CR 3-05 | 96509508 | 3 m3/h @ 23 m | 0,37 | |
| CR 3-06 | 96516593 | 3 m3/h @ 28 m | 0,55 | |
| CR 3-07 | 96516594 | 3 m3/h @ 33 m | 0,55 | |
| CR 3-08 | 96516595 | 3 m3/h @ 38 m | 0,75 | |
| CR 3-09 | 96516596 | 3 m3/h @ 43 m | 0,75 | |
| CR 3-10 | 96516597 | 3 m3/h @ 46 m | 0,75 | |
| CR 3-11 | 96516598 | 3 m3/h @ 52 m | 1,1 | |
| CR 3-12 | 96516599 | 3 m3/h @ 56 m | 1,1 | |
| CR 3-13 | 96516600 | 3 m3/h @ 61 m | 1,1 | |
| CR 3-15 | 96516601 | 3 m3/h @ 68 m | 1,1 | |
| CR 3-17 | 96516602 | 3 m3/h @ 82 m | 1,5 | |
| CR 3-19 | 96516603 | 3 m3/h @ 91 m | 1,5 | |
| CR 3-21 | 96516664 | 3 m3/h @ 104 m | 2,2 | |
| CR 3-23 | 96516665 | 3 m3/h @ 112 m | 2,2 | |
| CR 3-25 | 96516666 | 3 m3/h @ 121 m | 2,2 | |
| CR 3-27 | 96516667 | 3 m3/h @ 129 m | 2,2 | |
| CR 3-29 | 96516668 | 3 m3/h @ 139 m | 2,2 | |
| CR 3-31 | 96513350 | 3 m3/h @ 153 m | 3,0 | |
| CR 3-33 | 96513351 | 3 m3/h @ 161 m | 3,0 | |
| CR 3-36 | 96513352 | 3 m3/h @ 175 m | 3,0 | |
| CR5 | ||||
| CR 5-02 | 96516975 | 5 m3/h @ 9 m | 0,37 | |
| CR 5-03 | 96516976 | 5 m3/h @ 14 m | 0,55 | |
| CR 5-04 | 96516977 | 5 m3/h @ 19 m | 0,55 | |
| CR 5-05 | 96516978 | 5 m3/h @ 25 m | 0,75 | |
| CR 5-06 | 96516979 | 5 m3/h @ 31 m | 1,1 | |
| CR 5-07 | 96516990 | 5 m3/h @ 36 m | 1,1 | |
| CR 5-08 | 96516991 | 5 m3/h @ 41 m | 1,1 | |
| CR 5-09 | 96516992 | 5 m3/h @ 49 m | 1,5 | |
| CR 5-10 | 96516993 | 5 m3/h @ 54 m | 1,5 | |
| CR 5-11 | 96516994 | 5 m3/h @ 60 m | 2,2 | |
| CR 5-12 | 96516995 | 5 m3/h @ 66 m | 2,2 | |
| CR 5-13 | 96516996 | 5 m3/h @ 71 m | 2,2 | |
| CR 5-14 | 96516997 | 5 m3/h @ 76 m | 2,2 | |
| CR 5-15 | 96516998 | 5 m3/h @ 82 m | 2,2 | |
| CR 5-16 | 96516999 | 5 m3/h @ 87 m | 2,2 | |
| CR 5-18 | 96513388 | 5 m3/h @ 100 m | 3,0 | |
| CR 5-20 | 96513389 | 5 m3/h @ 111 m | 3,0 | |
| CR 5-22 | 96513381 | 5 m3/h @ 124 m | 4,0 | |
| CR 5-24 | 96513390 | 5 m3/h @ 135 m | 4,0 | |
| CR 5-26 | 96513391 | 5 m3/h @ 146 m | 4,0 | |
| CR 5-29 | 96513392 | 5 m3/h @ 164 m | 4,0 | |
| CR 5-32 | 96513393 | 5 m3/h @ 182 m | 5,5 | |
| CR 5-36 | 96513394 | 5 m3/h @ 202 m | 5,5 | |
| CR10 | ||||
| CR 10-01 | 96500979 | 10 m3/h @ 7 m | 0,37 | |
| CR 10-02 | 96500980 | 10 m3/h @ 15 m | 0,75 | |
| CR 10-03 | 96500981 | 10 m3/h @ 23 m | 1,1 | |
| CR 10-04 | 96500982 | 10 m3/h @ 31 m | 1,5 | |
| CR 10-05 | 96500983 | 10 m3/h @ 40 m | 2,2 | |
| CR 10-06 | 96500984 | 10 m3/h @ 48 m | 2,2 | |
| CR 10-07 | 96500985 | 10 m3/h @ 57 m | 3,0 | |
| CR 10-08 | 96501230 | 10 m3/h @ 64 m | 3,0 | |
| CR 10-09 | 96500987 | 10 m3/h @ 72 m | 3,0 | |
| CR 10-10 | 96501232 | 10 m3/h @ 81 m | 4,0 | |
| CR 10-12 | 96501233 | 10 m3/h @ 96 m | 4,0 | |
| CR 10-14 | 96501221 | 10 m3/h @ 114 m | 5,5 | |
| CR 10-16 | 96501222 | 10 m3/h @ 129 m | 5,5 | |
| CR 10-18 | 96501223 | 10 m3/h @ 149 m | 7,5 | |
| CR 10-20 | 96501224 | 10 m3/h @ 165 m | 7,5 | |
| CR 10-22 | 96501225 | 10 m3/h @ 180 m | 7,5 | |
