Spesifikasi DENYO DCA-500SPK SOUNDPROOF DIESEL GENERATING SETS
DENYO DCA-500SPK SOUNDPROOF DIESEL GENERATING SETS
Specifications
Model : DCA-500SPK
Alternator
Frequency ( Hz) : 50
60
Output Rating ( Kva)
Continous : 450
500
Standby : 495
550
No of Phase : 3-Phase, 4-Wire
Rated Voltage ( V) : Dual Voltage System Line 50 Hz : 190~ 220 or 380~ 440, 60Hz : 190~ 240 or 380~ 480
Poweer Factor : 0.8 ( Lagging)
Voltage Regulation ( % ) : Within ± 0.5
Excitation : Brushless , Rotating Exciter ( with A.V.R)
Instulation : Class F
Engine
Make & Model : Komatsu ( SA6D170-B)
Type : Inlined , Direct injected , Turboharged , Aftercooled
Output Rating
PS/ rpm : 520/ 1500
580/ 1800
kWmin¯ ¹ : 382/ 1500
427/ 1800
No of Cylinders-BoreXStroke ( mm) : 6-170x170
Piston Displacement ( L) : 23, 150
Fuel : ASTM No.2 Diesel Fuel or Equivalent
Fuel Consumption ( L/ h) : 69.5
83.1
Lube Oil Sump Capacity ( L) : 119
Coolant Capacity ( L) : 92.5
Battery Capacity ( V-Ah) : 190H52X2
Fuel Tank Capacity ( L) : 490
Unit
Dimensions
Length ( mm) : 5480 ( 5000)
Width ( mm) : 1650
Height ( mm) : 2400
Dry Weight ( kg) : 8540
Sound Level
7m/ db ( A) 1500/ 1800 rpm ( min¯ ¹ ) : 68
71
Specifications
Model : DCA-500SPK
Alternator
Frequency ( Hz) : 50
60
Output Rating ( Kva)
Continous : 450
500
Standby : 495
550
No of Phase : 3-Phase, 4-Wire
Rated Voltage ( V) : Dual Voltage System Line 50 Hz : 190~ 220 or 380~ 440, 60Hz : 190~ 240 or 380~ 480
Poweer Factor : 0.8 ( Lagging)
Voltage Regulation ( % ) : Within ± 0.5
Excitation : Brushless , Rotating Exciter ( with A.V.R)
Instulation : Class F
Engine
Make & Model : Komatsu ( SA6D170-B)
Type : Inlined , Direct injected , Turboharged , Aftercooled
Output Rating
PS/ rpm : 520/ 1500
580/ 1800
kWmin¯ ¹ : 382/ 1500
427/ 1800
No of Cylinders-BoreXStroke ( mm) : 6-170x170
Piston Displacement ( L) : 23, 150
Fuel : ASTM No.2 Diesel Fuel or Equivalent
Fuel Consumption ( L/ h) : 69.5
83.1
Lube Oil Sump Capacity ( L) : 119
Coolant Capacity ( L) : 92.5
Battery Capacity ( V-Ah) : 190H52X2
Fuel Tank Capacity ( L) : 490
Unit
Dimensions
Length ( mm) : 5480 ( 5000)
Width ( mm) : 1650
Height ( mm) : 2400
Dry Weight ( kg) : 8540
Sound Level
7m/ db ( A) 1500/ 1800 rpm ( min¯ ¹ ) : 68
71
