GW Instek LCR-6200 10Hz – 200kHz Precision LCR Meter
Perhatian!
Spesifikasi GW Instek LCR-6200 10Hz – 200kHz Precision LCR Meter
GW Instek LCR-6200 10Hz – 200kHz Precision LCR Meter
============================================================
Features
· 3.5” color LCD
· Consecutive test frequency
· Basic accuracy : 0.05%
· Measuring speed up to 25ms (max.)
· Full frequency range or spot OPEN/SHORT
· 16 major/secondary parameter measurement combinations and two additional monitoring parameters(maximum four different parameters can be shown simultaneously)
· DCR measurement and internal D.C. bias voltage (±2.5V)
· PASS/FAIL judgment
· Auto Level Control (ALC) function
· BIN function provides 9BIN and 1AUX, totally 10 BIN
· 10 steps listed tests to select different frequency, voltage and current criteria
· Standard interface : RS-232C, Handler and USB Host / Device
· Compact size, ideal for automatic equipment (2U,1/2 RACK)
============================================================
Specifications
TEST FREQUENCY : 10Hz – 200kHz (±0.01%) (4 digits resolution)
OUTPUT IMPEDANCE : 30Ω/50Ω/100Ω selectable
BASIC ACCURACY
-Slow/Med : 0.05%
-Fast : 0.1%
TEST SPEED : FAST : 25ms / MED : 100ms / SLOW : 333ms
TEST SIGNAL LEVELS
-AC Voltage : 10.00mV- 2.00V (±10%) CV : 10.00mV- 2.00V (±6%)
-AC Current : 100.0µA- 20.00mA (±10%) CC : 100.0 A- 20.00mA(±6%) (@2VMax)
-DCR : +2V, 0.066A(Max.), Output impedance fixed 30Ω
DC BIAS
-Internal : ±2.5V (0.5% + 0.005V)
LISTED MODE : 10 steps
BIN FUNCTION : Comparator (9BIN, AUX : 1BIN)
MEMORY
-INT – Panel Setting : 10 file name
-INT – Measured data: 10000 Data (.csv)
-USB Storage : 10 file name of setting, 9999 file name for data, 999 Log file for LCD screen
OTHER FUNCTIONS
-Auto Level Control (ALC) : ON/OFF
-Average : 1 – 256 times
-Trigger : INT/MAN/EXT/BUS
-Delay : 0ms – 60s
-Judgement : PASS/FAIL
-Screen Capture : Saving in to USB (Bmp form)
DISPLAY : 3.5” LCD, RGB color (320 x 240)
INTERFACE : RS-232(SCPI), Handler, USB Host
POWER SOURCE : AC 100V – 240V, 50 – 60Hz, Max. 15W
DIMENSIONS & WEIGHT : 265(W) x 107(H) x 312(D) mm; Approx. 3kg
ACCESSORIES : Safety Sheet x 1, Power Cord x 1, Test Fixture LCR-06B x 1, CD x 1 (User manual/PC software)
===========================================================
