GW Instek GPC-3060D 375W D.C. Power Supply

Update Terakhir
16-09-2022
Minimum Pembelian
1 Unit
Dilihat Sebanyak
5 kali
Lokasi
Banten - Tangerang Selatan - Pondok Aren
Harga
Rp. 13.781.000
Bagikan
+ Penawaran

Perhatian!

Perusahaan ini terdaftar sebagai Free Member. Hindari melakukan pembayaran sebelum bertemu penjual atau melihat barang secara langsung. COD (Cash On Delivery) atau bertemu langsung dengan penjual merupakan metode transaksi lebih aman.

Spesifikasi GW Instek GPC-3060D 375W D.C. Power Supply

GW Instek GPC-3060D 375W D.C. Power Supply

============================================================

Features

·         Triple Output

·         Auto Tracking

·         Auto Series and Parallel Operation

·         Constant Voltage and Constant Current Operation

·         Low Ripple and Noise

·         Internal Select for Continuous or Dynamic Load

·         Overload and Reverse Polarity Protection

·         3 1/2 Digits 0.5" LED Display

·         5V, 3A Fixed Output

============================================================

Specifications

DC OUTPUT

-CH1/CH2 : 0 – 30V/0 – 6A

-CH3 : 5V/3A Max

OPERATION MODE

-Indenpendent : Two independent outputs and 5V fixed output

-Series : Output from 0 to rating volts and 0 to rating amperes. Output from 0 to ± rating volts at rating amperes each

-Parallel : Output from 0 to double rating volts at rating amperes. Output from 0 to double rating amperes at rating volts

ConSTANT VOLTAGE OPERATION

-Regulation : Line regulation ≤0.01% + 3mV; Load regulation ≤0.01% + 3mV (rating current ≤3A), ≤0.01% + 5mV(rating current ≤10A), ≤0.02% + 5mV (rating current ≤10A)

-Ripple & Noise : ≤1mVrms 5Hz - 1MHz

-Recovery Time : ≤100µS (50% Load change, Minimum load 0.5A)

ConSTANT CURRENT OPERATION

-Regulation : Line regulation ≤0.2% + 3mA, Load regulation ≤0.2% + 5mA

-Ripple Current : ≤3mArms

5V FIXED OUTPUT

-Regulation : Line regulation ≤5mV, Load regulation ≤10mV

-Ripple & Noise : ≤2mVrms

-Voltage Accuracy : 5V ±0.25V

-Output Current : 3A

TRACKING OPERATION

-Tracking Error : ≤0.5% + 10mV of the master

-Series Regulation : ≤300mV

DISPLAY : 3 ½ digits 0.5” LED display

INSULATION

-Chassis and Terminal : 100MΩ or above (DC 1000V)

-Chassis and AC Cord : 100MΩ or above (DC 1000V)

POWER SOURCE : AC 100V/120V/220V/240V 10%, 50/60Hz

DIMENSIONS & WEIGHT : 255(W) x 145(H) x 420(D)mm

ACCESSORIES : User Manual x 1, Power Cord x 2, (15A/125V 2m for Japan) (10A/250V 1.5 without plug for Japan, North America and Europe only), CD-ROM (Remote Control Software) x 1

===========================================================

UNTUK MENGHINDARI PESANAN BARANG ANDA DITOLAK OLEH KAMI, SILAHKAN BERTANYA STOCK BARANG TERLEBIH DAHULU. TERIMA KASIH

Untuk informasi dan pemesanan, silahkan menghubungi :

Telp. & WA : 62.813.3117.0440

Mail : asiaindustri@gmail.com

============================================================



Tampilkan Lebih Banyak
