Denshi Handy Dissolved Oxygen Meter DO Meter ID-160T with makito ring DO Meter Handheld

Update Terakhir
21-12-2023
Minimum Pembelian
1 1
Dilihat Sebanyak
53 kali
Lokasi
DKI Jakarta - Jakarta Barat - Taman Sari
Harga
Rp. 26.400.000
Bagikan
+ Penawaran

Spesifikasi Denshi Handy Dissolved Oxygen Meter DO Meter ID-160T with makito ring DO Meter Handheld

 Denshi Handy Dissolved Oxygen Meter DO Meter
Type : ID-160T (with makito ring)
Origin : Japan

Now even tougher and more convenient!
Professional DO meter for on-site use

■Completely waterproof
■Shockproof
■Memory function
■2 year warranty on main unit
■1 year warranty on sensor

Measurement range
[DO]: 0.00~0.99mg/L or 1.0~20.0mg/L
[Water temperature]: -5.0~50.0℃

Comparison with conventional products :
- Main body type : ID-160T
- Oxygen sensor
(Wagnit®) Model: WA-TL
1 year warranty, cartridge type/diaphragm replaceable
- external structure With rubber protector (shock absorption function)
and winding wheel (cable winding structure)
- waterproof structure Dustproof and waterproof structure compliant with IP68, waterproof to a depth of 10m
- probe Double protection structure rubber cap (shock absorption function)
- Memory function Up to 30 records and history display possible
- Stability judgment function Automatic stability judgment function (with progress bar display function)
- Self-check function - Checks the sensor status after turning on the power and displays calibration timing, errors, etc.
- Displays the number of days remaining until the "1 year warranty" expiration date (from 30 days ago)
- Calibration method Easy calibration with air (no need for daily calibration, you can determine when calibration is required)
- Other functions ・Guidance display function
・Air saturation rate display function
・Time display function ・Initialization function
・Auto power off function
・Freshwater/seawater switching function
- Display method Monochrome TFT LCD display
- cable length 5m (standard) *10m specification also available

Specifications of Iijima Denshi Handy Dissolved Oxygen Meter DO Meter ID-160T

Main body type Diaphragm type galvanic cell type oxygen sensor (JIS K0102:2016 or later)
Oxygen sensor/model Wagnit®/WA-TL (1 year warranty, cartridge type/diaphragm replaceable)
Display method Monochrome TFT LCD display
Measurement range

DO: ①0.00~0.99mg/L ②1.0~20.0mg/L (when below 35℃) Auto range switching
water temperature: -5.0~50.0℃

Instrument accuracy
(main unit indicator only)

DO: ①±0.02mg/L (0.00~0.99mg/L range) (constant temperature)
②±0.1mg/L (1.0~20.0mg/L range) (constant temperature)
Water temperature: ±0.3℃ (0~35℃) in the case of)

Calibration method Easy calibration with air
Correction function Automatic temperature correction, manual chloride ion (seawater concentration) correction (by setting change)
Self-check function

・Checks the oxygen sensor status after turning on the power, and displays an error message when calibration is required, output abnormality, end of life, etc.
・Sensor warranty expiration notification function (displays the number of days remaining from 30 days before the warranty expiration date)

Other functions

・Guidance display function
・Air saturation rate display function
・Automatic stability judgment function (with progress bar display function)
・Time display function
・Memory function (records and reads out 30 measured values ​​in the main unit)
・Auto power off Function (If the change in DO value is within 1 mg/L for 30 minutes after the last key operation, the power is automatically turned off)
- Initialization function
- Freshwater/seawater switching function

Operating temperature limit 0~35℃
Storage temperature range 0~60℃
Body structure IP68 compliant dustproof/waterproof structure, waterproof structure to a depth of 10m
external structure

Body: With rubber protector (shock absorption function), winding ring (cable winding structure)
Probe: Double protection structure rubber cap (shock absorption function)

cable length Standard 5m *10m specification also available
power supply AAA alkaline batteries x 3 (DC4.5V) or nickel metal hydride batteries (rechargeable) x 3 (DC3.6V)
battery life Alkaline battery: Continuous approximately 360 hours
Body dimensions Approximately ⌀210×90(D)mm (including makitoire)
weight Approximately 800g (including batteries, probe, and makitoru)
Standard accessories

Oxygen sensor (Wagnit) model: WA-TL*, Membrane fluid replacement cartridge (with electrolyte)
, AAA alkaline battery, maintenance kit, instruction manual

Tampilkan Lebih Banyak
