Spesifikasi Oil Conductivity Meter EMCEE 1152 EMCEE 1153 DISTRIBUTOR EMCEE ELECTRONICS INDONESIA
Digital Conductivity Meter , ..............................................>>>> Harga Rp 62.300.000
Brand : Emcee Electronic ., Inc
Origin : USA
Type : 1152
(ASTMStandard Test Method D 2624 included in Specifications D975, D1655, and D7566)
Continuous standard electrical conductivity range from 1 to 2000 in increments of 1 picosiemen per meter (pS/m)
Available in other standard and non-standard conductivity ranges up to 20M pS/m
Large digital, liquid crystal display
Reliable advanced integrated circuit design technology
Self check calibration with field adjustment capability
Automatic over range and low battery indication
Capable of storage tank and tanker truck measurement with the use of a short cable or cable reel kit
Powered by 3 readily available alkaline batteries
Electronics housed in a rugged cast aluminum case coated with solvent resistant paint equipped with a detachable stainless steel probe
Approved intrinsically safe design for use in hazardous environments by Underwriters Laboratories (UL) U.S, (UL) Canada and LCIE (Europe)
====================================
=============================================
==================================================
2. Digital Conductivity Meter..............................................>>>> Harga Rp 68.400.000
Brand : Emcee Electronic ., Inc
Origin : USA
Type : 1153
(ASTM Standard Test Method D2624 included in Specifications D975, D1655, and D7566)
Aplikasi : untuk mengukur conductivity minyak
Spec :
Continuous standard electrical conductivity range from 1 to 2,000 picosiemens per meter (pS/m)
Available in other conductivity ranges (from 2000 - 10M pS/m)
LED illuminates during automatic test cycle (3 seconds)
Temperature measured and displayed in Celsius and Fahrenheit
Data stored (non volatile) until next test cycle is performed
Hermetically sealed
Text presentation of operational status
Automatic over range and low battery indications
Single pushbutton operation
Digital, liquid crystal display
Powered by 3 standard lithium cells
Approved intrinsically safe design for use in hazardous environments by Underwriters Laboratories (UL) U.S., (UL) Canada and LCIE (Europe)
Applications
The Model 1153 Digital Conductivity meter provides a measurement of electrical conductivity of fluids in conductivity units (CU), which are defined as picosiemens per meter in ASTM D 2624. The rugged Electro/mechanical design of the Model 1153 meter facilitates ease of use for both laboratory and field applications. Initially the meter was designed and developed for safety reasons to measure the electrical conductivity of hydrocarbon fuels, particularly jet fuels. Additional pre-amp versions are available to accommodate measurement of a variety of fluids for use in many different applications.
Safety
Hydrocarbon fuels typically have low electrical conductivity, and consequently, are susceptible to retaining a static charge. Static charges are induced, especially, when the fuel is pumped at high rates through filters. Due to the relatively low conductivity, the static charge does not readily dissipate and is retained for a considerable period of time. This condition can result in an explosion and/or fire. Since conductivity can vary with temperature, it is very important to record the fuel temperature at which the measurement was performed.
Brand : Emcee Electronic ., Inc
Origin : USA
Type : 1152
(ASTMStandard Test Method D 2624 included in Specifications D975, D1655, and D7566)
Continuous standard electrical conductivity range from 1 to 2000 in increments of 1 picosiemen per meter (pS/m)
Available in other standard and non-standard conductivity ranges up to 20M pS/m
Large digital, liquid crystal display
Reliable advanced integrated circuit design technology
Self check calibration with field adjustment capability
Automatic over range and low battery indication
Capable of storage tank and tanker truck measurement with the use of a short cable or cable reel kit
Powered by 3 readily available alkaline batteries
Electronics housed in a rugged cast aluminum case coated with solvent resistant paint equipped with a detachable stainless steel probe
Approved intrinsically safe design for use in hazardous environments by Underwriters Laboratories (UL) U.S, (UL) Canada and LCIE (Europe)
====================================
=============================================
==================================================
2. Digital Conductivity Meter..............................................>>>> Harga Rp 68.400.000
Brand : Emcee Electronic ., Inc
Origin : USA
Type : 1153
(ASTM Standard Test Method D2624 included in Specifications D975, D1655, and D7566)
Aplikasi : untuk mengukur conductivity minyak
Spec :
Continuous standard electrical conductivity range from 1 to 2,000 picosiemens per meter (pS/m)
Available in other conductivity ranges (from 2000 - 10M pS/m)
LED illuminates during automatic test cycle (3 seconds)
Temperature measured and displayed in Celsius and Fahrenheit
Data stored (non volatile) until next test cycle is performed
Hermetically sealed
Text presentation of operational status
Automatic over range and low battery indications
Single pushbutton operation
Digital, liquid crystal display
Powered by 3 standard lithium cells
Approved intrinsically safe design for use in hazardous environments by Underwriters Laboratories (UL) U.S., (UL) Canada and LCIE (Europe)
Applications
The Model 1153 Digital Conductivity meter provides a measurement of electrical conductivity of fluids in conductivity units (CU), which are defined as picosiemens per meter in ASTM D 2624. The rugged Electro/mechanical design of the Model 1153 meter facilitates ease of use for both laboratory and field applications. Initially the meter was designed and developed for safety reasons to measure the electrical conductivity of hydrocarbon fuels, particularly jet fuels. Additional pre-amp versions are available to accommodate measurement of a variety of fluids for use in many different applications.
Safety
Hydrocarbon fuels typically have low electrical conductivity, and consequently, are susceptible to retaining a static charge. Static charges are induced, especially, when the fuel is pumped at high rates through filters. Due to the relatively low conductivity, the static charge does not readily dissipate and is retained for a considerable period of time. This condition can result in an explosion and/or fire. Since conductivity can vary with temperature, it is very important to record the fuel temperature at which the measurement was performed.
