Konstruksi Baja Untuk futsal, Gedung, Gudang, Rumah Tinggal, Jembatan, Pabrik dan sarana prasarana i
Gambar Produk
Konstruksi Baja Untuk futsal, Gedung, Gudang, Rumah Tinggal, Jembatan, Pabrik dan sarana prasarana i
Update Terakhir
02-12-2013
Dilihat Sebanyak
352 kali
Lokasi
DKI Jakarta - Jakarta Selatan
Harga
Kontak Kami
Bagikan
+ Penawaran
Perhatian!
Perusahaan ini terdaftar sebagai Free Member. Hindari melakukan pembayaran sebelum bertemu penjual atau melihat barang secara langsung. COD (Cash On Delivery) atau bertemu langsung dengan penjual merupakan metode transaksi lebih aman.
Spesifikasi Konstruksi Baja Untuk futsal, Gedung, Gudang, Rumah Tinggal, Jembatan, Pabrik dan sarana prasarana i
Jenis-Jenis Baja & Besi
| Spesifikasi Bahan Wire Mesh | |||||||
|---|---|---|---|---|---|---|---|
| Wire Mesh | Diameter (mm) | Actual Weight (gr/mm) | Kekuatan Tarik (N/mm2) | Batas Ulur (N/mm2) | Elongation (%) | ||
| M4 | 4 | 15,45 | min 490 | min 400 | min 8% | ||
| M5 | 4,7 | 21,33 | min 490 | min 400 | min 8% | ||
| M5 | 4,5 | 19,55 | min 490 | min 400 | min 8% | ||
| M6 | 5,7 | 31,37 | min 490 | min 400 | min 8% | ||
| M6 | 5,5 | 29,2 | min 490 | min 400 | min 8% | ||
| M7 | 6,7 | 43,34 | min 490 | min 400 | min 8% | ||
| M7 | 6,5 | 40,79 | min 490 | min 400 | min 8% | ||
| M8 | 7,7 | 57,24 | min 490 | min 400 | min 8% | ||
| M8 | 7,5 | 54,31 | min 490 | min 400 | min 8% | ||
| M9 | 8,7 | 73,07 | min 490 | min 400 | min 8% | ||
| M9 | 8,5 | 69,75 | min 490 | min 400 | min 8% | ||
| M10 | 9,7 | 90,84 | min 490 | min 400 | min 8% | ||
| M10 | 9,5 | 87,13 | min 490 | min 400 | min 8% | ||
| M11 | 10,7 | 110,53 | min 490 | min 400 | min 8% | ||
| M11 | 10,5 | 106,44 | min 490 | min 400 | min 8% | ||
| M12 | 11,7 | 132,16 | min 490 | min 400 | min 8% | ||
| M12 | 11,5 | 127,68 | min 490 | min 400 | min 8% | ||
Spesifikasi Wire Mesh |
|||||||
Type |
Diameter (mm) |
Ukuran (m) |
Spasi (cm) |
Berat Table (kg/roll) |
Berat Actual Toleransi 0,2 mm (kg/roll) |
Berat Actual Toleransi 0,3 mm (kg/roll) |
Berat Actual Toleransi 0,5 mm (kg/roll) |
| M4 (coil) | 4 | 2,1 x 54 | 15 x 15 | 154,47 | 139,41 | 132,17 | 118,27 |
| M4 | 4 | 2,1 x 5,4 | 15 x 15 | 15,45 | 13,94 | 13,22 | 11,83 |
| M5 (coil) | 5 | 2,1 x 54 | 15 x 15 | 241,36 | 222,44 | 213,27 | 195,50 |
| M5 | 5 | 2,1 x 5,4 | 15 x 15 | 24,14 | 22,24 | 21,33 | 19,55 |
| M6 (coil) | 6 | 2,1 x 54 | 15 x 15 | 347,56 | 324,77 | 313,67 | 292,05 |
| M6 | 6 | 2,1 x 5,4 | 15 x 15 | 34,76 | 32,48 | 31,37 | 29,20 |
| M7 | 7 | 2,1 x 5,4 | 15 x 15 | 47,31 | 44,64 | 43,34 | 40,79 |
| M8 | 8 | 2,1 x 5,4 | 15 x 15 | 61,79 | 58,74 | 57,24 | 54,31 |
| M9 | 9 | 2,1 x 5,4 | 15 x 15 | 78,20 | 74,76 | 73,07 | 69,75 |
| M10 | 10 | 2,1 x 5,4 | 15 x 15 | 96,54 | 92,72 | 90,84 | 87,13 |
| M11 | 11 | 2,1 x 5,4 | 15 x 15 | 116,82 | 112,61 | 110,53 | 106,44 |
| M12 | 12 | 2,1 x 5,4 | 15 x 15 | 139,02 | 134,43 | 132,16 | 127,68 |
| Spesifikasi Produk Wire Mesh | |||||||
| Wire Mesh | Type | Line Kawat Utama | Line Kawat Melintang | Spasi | Ukuran (m) | ||
| M4 | Roll | 15 | 360 | 15 x 15 | 2.1 x 54 | ||
| M5 | Lembar | 15 | 36 | 15 x 15 | 2.1 x 5.4 | ||
| M5 | Roll | 15 | 360 | 15 x 15 | 2.1 x 54 | ||
| M6 | Lembar | 15 | 36 | 15 x 15 | 2.1 x 5.4 | ||
| M6 | Roll | 15 | 360 | 15 x 15 | 2.1 x 54 | ||
| M7 | Lembar | 15 | 36 | 15 x 15 | 2.1 x 5.4 | ||
| M7 | Lembar | 15 | 36 | 15 x 15 | 2.1 x 5.4 | ||
| M8 | Lembar | 15 | 36 | 15 x 15 | 2.1 x 5.4 | ||
| M8 | Lembar | 15 | 36 | 15 x 15 | 2.1 x 5.4 | ||
| M9 | Lembar | 15 | 36 | 15 x 15 | 2.1 x 5.4 | ||
| M9 | Lembar | 15 | 36 | 15 x 15 | 2.1 x 5.4 | ||
| M10 | Lembar | 15 | 36 | 15 x 15 | 2.1 x 5.4 | ||
| M10 | Lembar | 15 | 36 | 15 x 15 | 2.1 x 5.4 | ||
| M11 | Lembar | 15 | 36 | 15 x 15 | 2.1 x 5.4 | ||
| M11 | Lembar | 15 | 36 | 15 x 15 | 2.1 x 5.4 | ||
| M12 | Lembar | 15 | 36 | 15 x 15 | 2.1 x 5.4 | ||
| M12 | Lembar | 15 | 36 | 15 x 15 | 2.1 x 5.4 | ||
| Sectional Dimension for H Beam | Sectional Properties | |||||||||||||
| Geometrical | ||||||||||||||
| Sec.of | Unit | Moment of | ||||||||||||
| d | x | bf | tw | tf | r1 | H1 | H2 | Area | Weight | Inertia (cm4) | ||||
| mm | mm | mm | mm | mm | mm | mm | cm² | kg/m | Ix | Iy | ||||
| H | 100 | x | 50 | 5.0 | 7.0 | 8.0 | 15.0 | 70.0 | 11.85 | 9.30 | 187 | 15 | ||
| 100 | 6.0 | 8.0 | 10.0 | 18.0 | 64.0 | 21.90 | 17.19 | 383 | 134 | |||||
| H | 125 | x | 60 | 6.0 | 8.0 | 9.0 | 17.0 | 91.0 | 16.84 | 13.22 | 413 | 29 | ||
| 125 | 6.5 | 9.0 | 10.0 | 19.0 | 87.0 | 30.31 | 23.79 | 847 | 293 | |||||
| H | 150 | x | 75 | 5.0 | 7.0 | 8.0 | 15.0 | 120.0 | 17.85 | 14.01 | 666 | 49 | ||
| H | 148 | x | 100 | 6.0 | 9.0 | 11.0 | 20.0 | 108.0 | 26.8 | 21.07 | 1020 | 151 | ||
| H | 150 | x | 150 | 7.0 | 10.0 | 11.0 | 21.0 | 108.0 | 40.1 | 31.51 | 1640 | 563 | ||
| H | 175 | x | 90 | 5.0 | 8.0 | 9.0 | 17.0 | 141.0 | 23.1 | 18.09 | 1210 | 98 | ||
| 175 | 7.5 | 11.0 | 12.0 | 23.0 | 129.0 | 51.2 | 40.20 | 2880 | 984 | |||||
| H | 198 | x | 99 | 4.5 | 7.0 | 11.0 | 18.0 | 162.0 | 23.2 | 18.20 | 1580 | 114 | ||
| H | 200 | x | 100 | 5.5 | 8.0 | 11.0 | 19.0 | 162.0 | 27.2 | 21.32 | 1840 | 134 | ||
| H | 194 | x | 150 | 6.0 | 9.0 | 13.0 | 22.0 | 150.0 | 39.0 | 30.62 | 2690 | 507 | ||
| H | 200 | x | 200 | 8.0 | 12.0 | 13.0 | 25.0 | 150.0 | 63.53 | 49.87 | 4720 | 1600 | ||
| H | 248 | x | 124 | 5.0 | 80.0 | 12.0 | 20.0 | 208.0 | 32.68 | 25.65 | 3540 | 255 | ||
| H | 250 | x | 125 | 6.0 | 90.0 | 12.0 | 21.0 | 208.0 | 37.66 | 29.56 | 4050 | 294 | ||
| H | 244 | x | 175 | 7.0 | 11.0 | 16.0 | 27.0 | 190.0 | 56.24 | 44.15 | 6120 | 984 | ||
| H | 250 | x | 250 | 9.0 | 14.0 | 16.0 | 30.0 | 190.0 | 92.18 | 72.36 | 10800 | 3650 | ||
| H | 298 | x | 149 | 5.5 | 80.0 | 13.0 | 21.0 | 256.0 | 40.80 | 32.03 | 6320 | 442 | ||
| H | 300 | x | 150 | 6.5 | 9.0 | 13.0 | 22.0 | 256.0 | 46.78 | 36.72 | 7210 | 508 | ||
| H | 294 | x | 200 | 8.0 | 12.0 | 18.0 | 30.0 | 234.0 | 72.38 | 56.82 | 11300 | 1600 | ||
| H | 300 | x | 300 | 10.0 | 15.0 | 18.0 | 33.0 | 234.0 | 119.80 | 94.04 | 20400 | 6750 | ||
| 305 | 15.0 | 15.0 | 18.0 | 33.0 | 234.0 | 134.80 | 105.82 | 21500 | 7100 | |||||
| H | 346 | x | 174 | 6.0 | 9.0 | 14.0 | 23.0 | 300.0 | 52.68 | 41.35 | 11100 | 792 | ||
| H | 350 | x | 175 | 7.0 | 11.0 | 14.0 | 25.0 | 300.0 | 63.14 | 49.56 | 13600 | 984 | ||
| H | 340 | x | 250 | 9.0 | 14.0 | 20.0 | 34.0 | 272.0 | 101.50 | 79.68 | 21700 | 3650 | ||
| H | 350 | x | 350 | 12.0 | 19.0 | 20.0 | 39.0 | 272.0 | 173.90 | 136.51 | 40300 | 13600 | ||
| H | 396 | x | 199 | 7.0 | 11.0 | 16.0 | 27.0 | 342.0 | 72.16 | 56.65 | 20000 | 1450 | ||
| H | 400 | x | 200 | 8.0 | 13.0 | 16.0 | 29.0 | 342.0 | 84.12 | 66.03 | 23700 | 1740 | ||
| H | 390 | x | 300 | 10.0 | 160 | 22.0 | 38.0 | 314.0 | 136.00 | 106.76 | 38700 | 7210 | ||
| H | 400 | x | 400 | 13.0 | 21.0 | 22.0 | 43.0 | 314.0 | 218.70 | 171.68 | 66600 | 22400 | ||
| H | 450 | x | 200 | 9.0 | 14.0 | 18.0 | 32.0 | 386.0 | 96.76 | 75.96 | 33500 | 1870 | ||
| H | 440 | x | 300 | 11.0 | 18.0 | 24.0 | 42.0 | 356.0 | 157.40 | 123.56 | 56100 | 8110 | ||
| H | 496 | x | 199 | 9.0 | 14.0 | 200 | 34.0 | 428.0 | 101.30 | 79.52 | 41900 | 1840 | ||
| H | 500 | x | 200 | 10.0 | 16.0 | 20.0 | 36.0 | 428.0 | 114.20 | 89.65 | 47800 | 2140 | ||
| H | 482 | x | 300 | 11.0 | 15.0 | 26.0 | 41.0 | 400.0 | 145.50 | 114.22 | 60400 | 6760 | ||
| H | 488 | x | 300 | 11.0 | 18.0 | 26.0 | 44.0 | 400.0 | 163.50 | 128.35 | 71000 | 8110 | ||
| H | 596 | x | 199 | 10.0 | 15.0 | 22.0 | 37.0 | 522.0 | 120.50 | 94.59 | 68700 | 1980 | ||
| H | 600 | x | 200 | 11.0 | 17.0 | 22.0 | 39.0 | 522.0 | 134.40 | 105.50 | 77600 | 2280 | ||
| H | 582 | x | 300 | 12.0 | 17.0 | 28.0 | 45.0 | 492.0 | 174.50 | 136.98 | 103000 | 7670 | ||
| H | 588 | x | 300 | 12.0 | 20.0 | 28.0 | 48.0 | 492.0 | 192.50 | 151.11 | 118000 | 9020 | ||
| H | 700 | x | 300 | 13.0 | 24.0 | 28.0 | 52.0 | 596.0 | 215.50 | 184.87 | 201000 | 10800 | ||
| H | 800 | x | 300 | 14.0 | 26.0 | 28.0 | 54.0 | 692.0 | 267.40 | 209.91 | 292000 | 11700 | ||
| H | 900 | x | 300 | 16.0 | 28.0 | 28.0 | 56.0 | 788.0 | 309.80 | 243.19 | 411000 | 12600 | ||
Sectional Dimension H Beam |
|||||||||||||||
| Radius of | Modulus of | Compact | *) | *) | |||||||||||
| Gyration of | Section | Section | rT | d/Af | Lc | Lu | |||||||||
| d | x | bf | Area (cm) | (cm3) | Criteria | (cm) | (1/cm) | (cm) | (cm) | ||||||
| mm | mm | ix | iy | Sx | Sy | bf/2tf | d/tw | ||||||||
| H | 100 | x | 50 | 3.97 | 1.12 | 37 | 6 | 3.57 | 20.00 | 1.32 | 2.86 | 63.70 | 1,969 | ||
| 100 | 4.18 | 2.47 | 77 | 27 | 6.25 | 16.67 | 2.75 | 1.25 | 127.50 | 4,501 | |||||
| H | 125 | x | 60 | 4.95 | 1.32 | 66 | 10 | 3.75 | 20.83 | 1.57 | 2.60 | 76.50 | 2,160 | ||
| 125 | 5.29 | 3.11 | 136 | 47 | 6.94 | 19.23 | 3.44 | 1.11 | 159.30 | 506.30 | |||||
| H | 150 | x | 75 | 5.11 | 1.67 | 89 | 13 | 5.36 | 30.00 | 1.96 | 2.86 | 95.60 | 196.90 | ||
| H | 148 | x | 100 | 6.16 | 2.37 | 138 | 30 | 5.56 | 24.67 | 2.70 | 1.64 | 127.50 | 342.10 | ||
| H | 150 | x | 150 | 6.39 | 3.75 | 219 | 75 | 7.50 | 21.43 | 4.13 | 1.00 | 191.20 | 562.60 | ||
| H | 175 | x | 90 | 7.25 | 2.06 | 138 | 22 | 5.63 | 35.00 | 2.39 | 2.43 | 114.70 | 2,315 | ||
| 175 | 7.50 | 4.38 | 329 | 112 | 7.95 | 23.33 | 4.82 | 0.91 | 223.10 | 6,188 | |||||
| H | 198 | x | 99 | 8.26 | 2.22 | 160 | 23 | 7.07 | 44.00 | 2.61 | 2.86 | 1,262 | 196.90 | ||
| H | 200 | x | 100 | 8.23 | 2.22 | 184 | 27 | 6.25 | 36.36 | 2.62 | 2.50 | 127.50 | 225.00 | ||
| H | 194 | x | 150 | 8.30 | 3.61 | 277 | 58 | 8.33 | 32.33 | 4.07 | 1.44 | 1,912 | 3,915 | ||
| H | 200 | x | 200 | 8.62 | 5.02 | 472 | 160 | 8.33 | 25.00 | 5.51 | 0.83 | 254.9 | 675.1 | ||
| H | 248 | x | 124 | 10.41 | 2.79 | 285 | 41 | 7.75 | 49.60 | 3.28 | 2.50 | 158.1 | 225.0 | ||
| H | 250 | x | 125 | 10.37 | 2.79 | 324 | 47 | 6.94 | 41.67 | 3.29 | 2.22 | 159.3 | 253.2 | ||
| H | 244 | x | 175 | 10.43 | 4.18 | 502 | 112 | 7.95 | 34.86 | 4.74 | 1.27 | 223.1 | 443.8 | ||
| H | 250 | x | 250 | 10.82 | 6.29 | 864 | 292 | 8.93 | 27.78 | 6.90 | 0.71 | 318.7 | 787.6 | ||
| H | 298 | x | 149 | 12.45 | 3.29 | 424 | 59 | 9.31 | 54.18 | 3.90 | 2.50 | 189.9 | 225.0 | ||
| H | 300 | x | 150 | 12.41 | 3.30 | 481 | 68 | 8.33 | 46.15 | 3.91 | 2.22 | 191.2 | 253.2 | ||
| H | 294 | x | 200 | 12.49 | 4.70 | 769 | 160 | 8.33 | 36.75 | 5.38 | 1.22 | 254.9 | 459.3 | ||
| H | 300 | x | 300 | 13.05 | 7.51 | 1360 | 450 | 10.00 | 30.00 | 8.26 | 0.67 | 382.40 | 843.9 | ||
| 305 | 12.63 | 7.26 | 1433 | 466 | 10.17 | 20.00 | 8.22 | 0.66 | 388.8 | 857.9 | |||||
| H | 346 | x | 174 | 14.52 | 3.88 | 642 | 91 | 9.67 | 57.67 | 4.57 | 2.21 | 221.80 | 254.6 | ||
| H | 350 | x | 175 | 14.68 | 3.95 | 777 | 112 | 7.95 | 50.00 | 4.61 | 1.82 | 223.1 | 309.4 | ||
| H | 340 | x | 250 | 14.62 | 6.00 | 1276 | 292 | 8.93 | 37.78 | 6.78 | 0.97 | 318.7 | 579.1 | ||
| H | 350 | x | 350 | 15.22 | 8.84 | 2303 | 777 | 9.21 | 29.17 | 9.66 | 0.53 | 455.3 | 1113.5 | ||
| H | 396 | x | 199 | 16.65 | 4.48 | 1010 | 146 | 9.05 | 56.57 | 5.25 | 1.81 | 253.7 | 311.0 | ||
| H | 400 | x | 200 | 16.79 | 4.55 | 1185 | 174 | 7.69 | 50.00 | 5.29 | 1.54 | 254.9 | 365.7 | ||
| H | 390 | x | 300 | 16.87 | 7.28 | 1985 | 481 | 9.38 | 39.00 | 8.17 | 0.81 | 382.4 | 692.4 | ||
| H | 400 | x | 400 | 17.45 | 10.12 | 3330 | 120 | 9.52 | 30.77 | 11.05 | 0.48 | 520.4 | 1230.7 | ||
| H | 450 | x | 200 | 18.61 | 4.40 | 1489 | 187 | 7.14 | 50.00 | 5.22 | 1.61 | 254.9 | 350.1 | ||
| H | 440 | x | 300 | 18.88 | 7.18 | 2550 | 541 | 8.33 | 40.00 | 8.12 | 0.81 | 390.3 | 719.2 | ||
| H | 496 | x | 199 | 20.34 | 4.26 | 1690 | 185 | 7.11 | 55.11 | 5.14 | 1.78 | 253.7 | 316.0 | ||
| H | 500 | x | 200 | 20.46 | 4.33 | 1912 | 214 | 6.25 | 50.00 | 518 | 1.56 | 254.9 | 360.1 | ||
| H | 482 | x | 300 | 20.37 | 682 | 2506 | 451 | 1,000 | 43.82 | 7.96 | 1.07 | 382.4 | 525.2 | ||
| H | 488 | x | 300 | 20.84 | 7.04 | 2910 | 541 | 8.33 | 44.36 | 8.05 | 0.90 | 390.3 | 648.5 | ||
| H | 596 | x | 199 | 23.88 | 4.05 | 2305 | 199 | 6.63 | 59.60 | 5.01 | 2.00 | 253.7 | 281.8 | ||
| H | 600 | x | 200 | 24.03 | 4.12 | 2587 | 228 | 5.88 | 54.55 | 5.06 | 1.76 | 250.2 | 332.1 | ||
| H | 582 | x | 300 | 24.30 | 6.63 | 3540 | 511 | 8.82 | 48.50 | 7.86 | 1.14 | 390.3 | 513.5 | ||
| H | 588 | x | 300 | 24.76 | 6.85 | 4014 | 601 | 7.50 | 49.00 | 7.96 | 0.98 | 390.3 | 598.0 | ||
| H | 700 | x | 300 | 29.21 | 6.77 | 5743 | 720 | 6.25 | 53.85 | 7.92 | 0.97 | 390.3 | 602.8 | ||
| H | 800 | x | 300 | 33.05 | 6.61 | 7300 | 780 | 5.77 | 57.14 | 7.83 | 1.03 | 390.3 | 571.4 | ||
| H | 900 | x | 300 | 36.42 | 6.38 | 9133 | 840 | 5.36 | 56.25 | 7.69 | 1.07 | 390.3 | 547.0 | ||
| Note : | ||||||||||
| *) Material : JIS G 3101 - SS 400 | ||||||||||
| Fy = 2500 kg/cm² if | tf | [ | 16 mm | |||||||
| Fy = 2400 kg/cm² if | 16 mm < | tf | [ | 40 mm | ||||||
| Fy = 2200 kg/cm² if | tf | > | 40 mm | |||||||
Konstruksi Baja
Konstruksi Baja ini bergerak di bidang konstruksi besi dan baja untuk futsal, Gedung, Gudang, Rumah Tinggal, Jembatan, Pabrik dan sarana prasarana infrastuktur lainnya. Dengan pengalaman dan perjalanan yang cukup panjang, kami hadir untuk memberikan anda solusi yang tepat bagi pembangunan tersebut. Kami dapat membantu anda dalam hal design struktur dari segi konstruksi baja sehingga apa yang anda harapkan dapat terealisasi. Workshop kami mempunyai peralatan untuk konstruksi baja yang lengkap yang terdiri dari: gas cutting machine, shearing machine, welding machine dan crane.Tidak hanya peralatan kami juga memiliki Man Power yang cukup handal dan dapat dipercaya melayani kebutuhan Anda dengan hasil yang terbaik, serta kepuasaan pelanggan adalah kepuasan kami. Berikut adalah beberapa foto referensi proyek yang telah kami kerjakan:
ini adalah gambar disign Pabrik yang telah kami kerja di kawasan Jawa Barat untuk pembuatan Pabrik BioGas.
Ini adalah Struktur Pabrik dalam pengerjaan.Demikian lembar pengenalan usaha kami
Salam Hangat,
Konstruksi Baja
