Laser Leica DISTO D810 touch

Laser Leica DISTO D810 touch

World’ s first the Leica DISTO D810 touch is the first laser distance meter world
wide with a touch screen, allowing for quick and intuitive operation. Another
revolutionary feature allows for measurements with pictures. Due to the integrated
camera it is also possible to take pictures and download them with the USB interface
to a computer. The high functionality is perfectly completed by the smart free app “ Leica DISTO sketch” .

• Touchscreen
• Pointfinder with 4x zoom and overview camera
• Camera function with USB download
• Measure with a picture
• Precise 360° tilt sensor
• Smart Horizontal Mode
• Height tracking
• Bluetooth Smart
• Free App Leica DISTO sketch
• Li-Ion battery

Description

• Simply touch it
Large touch screen for quick and intuitive operation. Using common gestures such as
swipe and zoom with two fingers, all the functions are simply and easily accessible.
Measurements can also be taken using the touch screen. This avoids unintentionally
moving the Leica DISTO D810 touch during the measurement.

• Measure with a picture
It has never been easier to determine the width, height, area or even the diameter of
an object. One measurement at right angles to the object is all it takes. Then the desired
dimension is marked using two arrows in the picture and the measured value appears in
the display. In addition to the zoom stages on the Pointfinder, an overview camera is available
for large objects.

• Documentation using pictures
The camera function on the Leica DISTO D810 touch can be used to create pictures or screen
shots for recording purposes, which can then be downloaded to a computer via the USB interface.
No details about the measured target points need be lost.

• Highest precision
The Leica DISTO D810 touch offers a number of indirect measuring functions. Due to the specially
developed tilt sensor the results are very precise. Even more accurate results can be achieved
using the Leica FTA360 tripod adapter with its fine adjustment allowing exact targeting.

• Flexible data transfer
In keypad mode, you can link your Leica DISTO D810 touch to your computer and send measured
values in the form of a keyboard entry to any program. This provides a high degree of flexibility.

• Bluetooth Smart and new free App Leica DISTO sketch
The further developed App " Leica DISTO sketch " is the ideal link between the Leica DISTO with
Bluetooth Smart and a smartphone or a tablet. It allows you to create fast scaled drawings, dimension
objects in pictures and checking construction drawings. It is even possible to integrate detailed
sketches in an existing sketch, e.g. to a plan view. This allows you to have all the information together
in a single document. The files can then be sent by e-mail directly to the office.

• ISO Standard 16331-1 The standard for laser distance meters
Range and accuracy of laser distance meters depend on light conditions and the reflectiveness
of the measuring target. For Leica Geosystems it is important that the instruments not only perform
under perfect laboratory conditions, but above all under the kind of everyday working conditions
encountered on construction sites. This is why, working together with external experts, the company
have developed a standard by which laser distance meters can be tested and compared with each other.

Product Information

• Leica DISTO D810 touch laser distance meter
• Holster
• Hand loop
• USB charger incl 4 plugs

specifications

• Typical measuring accuracy : ± 1 mm
• Range : up to 200 m
• Measuring units : m, ft, in
• Power Range Technology : YES
• Distance in : meters Ø of the laser dot in mm : 10, 50, 100 m 6, 30, 60 mm
• Tilt sensor measuring range : 360°
• Pointfinder with 4x zoom : YES
• Overview camera : YES
• Photograph file format : jpg
• Memory : 30 displays
• Free software for Windows : YES
• Free App : iOS / Android
• Data interface : Bluetooth® Smart
• Measurements per set of batteries : up to 4000* *
• Multifunctional end piece : automatic recognition
• Batteries : Li-ion rechargeable
• Tripod thread : YES
• Protection class : IP 54
• Dimensions : 164x61x31 mm
• Weight with batteries : 238 g

Functions

• Distance measurement : YES
• Minimum / maximum measurement : YES
• Area / volume measurement : YES
• Trapezium function : YES
• Pythagoras functions : 2 points and 3 points
• Inclination tracking : YES
• Smart Horizontal Mode : YES
• Sloped object measurement : YES
• Height tracking : YES
• Height profile measurements : YES
• Stake out function : a/ b
• Pictures / screenshots : YES
• Gallery with USB-download : YES
• Measure with the picture : YES
• Compass : YES
• Calculator : YES
