GW INSTEK GDS-3000 Series
Perhatian!
Spesifikasi GW INSTEK GDS-3000 Series
-
500/350/250/150MHz with 2/4 Channels
-
5GSa/s RT or 100GSa/s ET Sampling Rate
-
Independent Memory for Each Channel
-
VPO Technology
-
Large 8-inch 800x600 Display
-
Split Screen Function
-
3 Built-in Impedances (50Ω/75Ω/1MΩ)
-
Power Analysis Software (Optional)
-
Serial Bus Analysis Software for I2C, SPI and UART (Optional)
Specification
| GDS-3504 | GDS-3502 | GDS-3354 | GDS-3352 | GDS-3254 | GDS-3252 | GDS-3154 | GDS-3152 | |
| Waveform Technology | VPO ( Visual Persistence Oscilloscope ) | |||||||
| Display |
8" TFT LCD SVGA |
|||||||
| Bandwidth (MHz) |
500 |
500 | 350 | 350 | 250 | 250 | 150 | 150 |
| Number of Channel |
4 |
2 | 4 | 2 | 4 | 2 | 4 | 2 |
| Memory Depth |
25k per channel |
|||||||
| Sample Rate |
4GSa/s (RTS) |
5GSa/s (RTS) |
||||||
| Vertical Resolution | 8-bit | |||||||
| Vertical Sensitivity | 2mV/div ~ 5V/div(@1MΩ) 2mV/div ~ 1V/div (@50/75Ω) |
|||||||
| Time Base Range | 1ns/div ~ 100s/div (1-2.5-5 increments) |
|||||||
| Input Impedance Selection | 1MΩ / 75Ω / 50Ω | |||||||
| Auto Measurement | 28 | |||||||
| Waveform Memory | 24 | |||||||
| Panel Setup Memory | 20 | |||||||
| Auto-Set | V | |||||||
| Auto/Normal Trigger | V | |||||||
| ALT Trigger | V | |||||||
| TV Trigger | V | |||||||
| Cursor Readout | V | |||||||
| XY Mode | V | |||||||
| Zoom | V | |||||||
| Go/NoGo | V | |||||||
| Zoom FFT | V, *It Support From App Software. | |||||||
| Counter Function | V | |||||||
| Function Generator | - | |||||||
| Logic Analyzer | - | |||||||
| Data Logger | - | |||||||
| Digital Storage | V | |||||||
| Go/NoGo Output | V | |||||||
| Interface | USB Host/Device, RS-232, GPIB(Opt.), Lan | |||||||
| SVGA Output | V | |||||||
| Buzzer Alarm | V | |||||||
| PictBridge Compatible | V | |||||||
| Battery Power Operation | - | |||||||
| LED Indicators | - | |||||||
| Z-Axis Input | - | |||||||
| LabView Driver | V | |||||||
| Power Source | AC 100V ~ 240V |
|||||||
